7.3 RT EQUIPMENT

Radio Talkback equipment may be supplied by Trilogy as part of a complete system. It is not
manufactured by Trilogy and will be supplied with the original equipment manuals.
The usual configuration consists of one or more Base Stations and a number of portable
transceivers. The Base Stations are connected to the matrix using normal 4 wire audio ports
according to the pin-out information in Section 2.

7.4 500-22-00 ICIS-1 ISDN INTERFACE

The 500-22 ICIS-1 ISDN interface is connected in the same manner as the Telos Hybrid
(see Section 0). The 1U package contains two 64k-bandwidth channels, which may be used
independently or as a single ISDN2 (128k) bandwidth channel.
To make correct use of the available bandwidth, two separate telephone interface cards
(500-19-10) should be allocated, along with two matrix ports. It is possible to request two
independent incoming telephone numbers, either via your in-house switchboard of (if
appropriate) from your telco. In this way, incoming calls can be directed to either Bearer 1 or
2 and outgoing calls will be connected to the first available Bearer. Careful programming
within the telephone groups area of PathFinder is required to obtain the best results.

7.4.1 500-22-00 ICIS-1 ISDN INTERFACE CONNECTOR PIN-OUTS

7.4.1.1 Bearer 1 & Bearer 2
Audio Input – XLR3 fixed socket
Audio output – XLR3 fixed plug
D15 fixed socket
Page 58 of 81
Commander Installation Guide
Pin 1
Pin 2
Pin 3
Pin 1
Pin 2
Pin 3
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
Pin 9
Pin 10
Pin 11
Pin 12
Pin 13
Pin 14
Pin 15
Issue 9.1
Ground
Balanced input 1
Balanced input 2
Ground
Balanced output 1
Balanced output 2
AUTO control input
DROP control input
+5VDC
D8 DTMF output
D4 DTMF output
D2 DTMF output
D1 DTMF output
Not connected
SIEZE control input
Ground
Line Mode output
Automode output
DTMF data valid
Not connected
Not connected
