Icom IC-F6061 Service Manual page 27

SECTION 8
[CHASSIS PARTS]
REF ORDER
NO. NO.
J1 6510004880 MR-DSE-01
MP1 8010020540 2979 CHASSIS
MP2 8930070860 O-RING (BM)
MP3 8110008960 2979 COVER
MP4 8930070920 2979 D-SUB PLATE
MP5 8510018090 2979 FILTER CASE
MP8 8930048550 2177 CLIP
MP9 8810008661 Screw BT B0 3X8 NI-ZC3 (BT)
MP10 8810008661 Screw BT B0 3X8 NI-ZC3 (BT)
MP11 8810008661 Screw BT B0 3X8 NI-ZC3 (BT)
MP12 8810009991 Screw BT B0 3X8 NI-ZK3 (BT)
MP13 8810009991 Screw BT B0 3X8 NI-ZK3 (BT)
MP14 8930071670 2979 M-PLATE
MP16 8930068420 SPONGE (IS)
[FRONT UNIT]
REF ORDER
NO. NO.
J503 6450002210 3017-8821
DS501 5030003020 L6-0226TVM-3
SP501 2510001400 3050S-E6227
W501 8900012711 OPC-1297A
W502 7120000470 ERDS2T0
W503 7120000470 ERDS2T0
EP502 8930072220 SRCN-2979-SP-N-W
MP501 8210023260 2979 FRONT PANEL
MP502 8310068050 2979 WINDOW PLATE
MP503 8210023270 2979 REFLECTOR
MP504 8930070840 2979 LENS
MP505 8610013020 KNOB N-352
MP506 8930070830 2979 KEYBOARD
MP507 8930070850 2979 VOL RUBBER
MP508 8010020570 2979 SUB CHASSIS
MP509 8930071350 2979 SPRING
MP510 8510018080 2979 LCD PLATE
MP511 8930071600 INSULATION SHEET (LR)
MP513 8930071610 2979 LCD FILTER
MP514 8930059000 2601 SP NET
MP515 8610007420 knob spring NO.6601
MP516 8810010501 Screw BT B0 3X10NI-ZC3 (BT)
MP517 8930045910 Thermal sheet (BS)
[MAIN UNIT]
REF ORDER
NO. NO.
J7 6450000140 HSJ0807-01-010
W1 7120000470 ERDS2T0
W2 8900016250 OPC-1701
EP4 6910010280 HF70BB9.5X10.4X4.9
EP5 6910010280 HF70BB9.5X10.4X4.9
EP7 6910011560 HF70BB4.5X5X1.6
MP1 8510018070 2979 VCO CASE
MP2 8510018060 2979 VCO COVER
MP3 8510002280 VCOSheild plate (A)
MP4 8930058840 Shield sponge (T)
Screw abbreviations
MECHANICAL PARTS
DESCRIPTION
DESCRIPTION
DESCRIPTION
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[CONNECT UNIT]
REF ORDER
QTY.
NO. NO.
J602 6510023210 CD6125SA1J0
1
W601 8900012711 OPC-1297A
1
1
1
1
1
1
[ACCESSORIES]
10
2
REF ORDER
2
NO. NO.
4
2
MC1 Optional product HM-148
1
Optional product HM-152
W1 Optional product OPC-1132
OPC-1194A
Optional product
W2 8900000731 OPC-049A
MP1 8010020610 2979 MOBILE BRACKET
MP2 8820000530 Flange bolt M4X8 NI
QTY.
MP3 8810000471 Screw PH (+-) M5X12 ZC3
MP4 8810000951 Screw BT A0 5X16 ZC3
1
MP5 8850000180 Flat washer M5 SUS
MP6 8850000391 SPRING WASHER M5 ZC3
1
MP7 8830000121 Nut M5 ZC3
MP8 8950005110 2289 MIC HANGER
1
MP10 8310068720 2979 LCD SEAL
MP11 8930059160 2601 FELT
1
MP12 8810004700 Screw BT A0 3X16 SUS
1
MP13 8930072530 SPONGE (JN)
1
2
MC1
1
1
1
1
1
1
1
1
W1
1
1
2
1
1
1
3
1
MP1
QTY.
1
1
1
MP11
(already attached)
1
1
2
1
1
1
1
8 - 1
DESCRIPTION
DESCRIPTION
[USA-01], [USA-02]
[EXP-01], [EUR-01], [EXP-02]
[USA-01], [USA-02]
[EXP-01], [EUR-01], [EXP-02]
W2
MP8
MP12
MP10
MP13
MP5 MP2
MP6 MP3
(M5×12)
MP7
MP4
(M5×16)
QTY.
1
1
QTY.
1
1
1
1
1
1
4
4
4
4
4
4
1
1
2
2
2
