Basic of the Sunny WebBox

3 Basic of the Sunny WebBox
3.1 User Interface
The user interface permits quick access to all important information about the PV plant and its devices.
Item Description
A Icon Bar
B Plant Tree
C Device Menu
D Contents section
14 SWebBox20-eng-BUS111312
Meaning
The icon bar gives you quick access to the main functions of the
Sunny WebBox.
In the plant tree, all devices in a PV system are represented in a
tree structure.
The device menu enables you to retrieve information and configure
devices selected in the plant tree.
The contents section shows the actual contents. The contents are
determined by the device menu.
