I n t e n t o f U s e
R a n g e o f F a s t e n e r s
nG4 is a hydro-pneumatic tool designed to place
®
Avdel breakstem fasteners at high speed making it
ideal for batch or flow-line assembly in a wide
variety of applications throughout all industries. It
can place all fasteners listed opposite.
The tool features a vacuum system for fastener
retention and trouble free collection of the spent
stems regardless of tool orientation.
A complete tool is made up of three separate
elements which will be supplied individually.
See diagram below.
NOSE EQUIPMENT MUST BE FITTED AS
DESCRIBED ON PAGE 9.
P a r t N u m b e r i n g
The part number of the base tool remains the same whichever nose assembly, or nose tip is fitted. See the General Assembly
1
pages 24 and 25.
This single nose assembly will allow placing of non-aerospace fasteners by simply selecting the appropriate
2
nose tip from the range of Type 1 Nose Tips. Other nose assemblies are available for applications with
restricted access, for aerospace and special fasteners see table page 12.
NOSE ASSEMBLY
2
71210-15000
BASE TOOL
1
71233-02000
6
FASTENER
NAME
®
AVEX
®
STAVEX
®
AVINOX
AVIBULB ®
BULBEX ®
T-LOK ®
®
AVDEL SR
®
INTERLOCK
®
HEMLOK
®
TLR
MAXLOK ®
AVTAINER ®
AVDEL ®
®
MBC
®
MBC/LC
AVSEAL II
®
Q TM RIVET
T TM RIVET
CHERRYMATE TM
The nose tip part number relates to a specific fastener. If access to the application is
3
restricted, some extended nose tips are available. See table page 12.
NOSE TIP
3
see note 3
Inc.
FASTENER SIZE (
4.3 4.8 5 5.2 6 6.4 6.5
3 1
– / – – – /
16 4
1 + +
2 3
*
ADD 3 DIGITS FROM THE
LAST COLUMN OF A NOSE
TIP TABLE ON PAGE 10, 11 or
12.
MM
)
IN
7 8 9 9.5 10 11
3
– – – – / – –
8
=
COMPLETE TOOL
71233-00 . . .
*
12
–
