GENERAL INFORMATION
Please read and retain this manual. The information within
describes the proper procedures for safely installing,
operating and maintaining your motor.
The description and specifications contained herein were
in effect at the time this manual was approved for printing.
MotorGuide, whose policy is one of continual
improvement, reserves the right to discontinue models at
any time, to change specifications, designs, and methods
of procedure without notice and without incurring
obligation.
Safety and operating information that is practiced along
with good common sense can help prevent personal injury
and product damage.
!
WARNING
DIGITAL MOTORS:
If the motor automatically throttles back, it
indicates something may be wrong with the motor
and it should be taken in for service.
!
WARNING
DIGITAL MOTORS:
A slight voltage drain occurs when the trolling
motor is continually connected to the battery for
extended periods of time. To prevent battery drain
when not in use fro an extended period,
disconnect the trolling motor from the power
source.
CAUTION
Disconnect the trolling motor from the battery(s)
before charging.

Safety DO's and DON'Ts

!
Do not allow children to operate the trolling motor
without adult supervision.
!
Do not modify the unit in any way or add accessories
other than approved MotorGuide accessories.
!
Do not power-wash your trolling motor.
!
Do disconnect the power from the motor when
replacing the prop, removing debris around the prop,
charging batteries, putting your boat on a trailer or
when the motor is not in use.
!
Do make sure the foot pedal is secured and the motor
is securely locked into the stowed position when using
a gasoline motor to move to another location, or when
putting your boat on a trailer.
90-MM6900
Do secure loose items on your boat before traveling
!
at high speeds across the water.

How to Use This Manual

Review the following information carefully. These
notices will alert you to potential dangers and
important information.
The observance of WARNINGS and CAUTIONS
alone does not eliminate the possibility of personal
injury or product damage. Your close attention to the
performance of recommended service procedures
and the practice of responsible personal safety are
major accident prevention measures.
!
WARNING
Failure to follow a safety WARNING can result in
bodily injury.
CAUTION
Failure to observe CAUTION instructions can result in
failure or damage to the product or equipment.
INFORMATION
Signifies important information about your trolling
motor.
NOTE
Signifies a statement calling attention to general
information about your trolling motor.

Specifications

Model Volts
T25 12
T30 12
30 12
36 12
40 12
46 12
54 12
71 24
54 V 12
70 V 24
71 V 24
82 V 24
109 V 36
54 V DS 12
82 V DS 24
109 V DS 36
Kwatts Kilos
0.20 6.11
0.20 6.11
0.20 7.08
0.25 7.7
0.25 7.7
0.28 8.17
0.34 10.7
0.48 15.92
0.34 10.7
0.48 15.92
0.48 19.92
0.78 22.4
0.88 24.2
0.34 10.7
0.78 21.8
0.88 23.3
2
