PARTS – TORCH AND CONSUMABLES

T100M Machine Torch Assembly

Item Part Number Description
059265* T100M Machine Torch Assembly with 25 ft (7.6 m) Lead
059268* T100M Machine Torch Assembly with 35 ft (10.7 m) Lead
059272* T100M Machine Torch Assembly with 50 ft (15.2 m) Lead
1 128754
2 027889
3 058519
4 128639
5 075571
6 128768
7 128643
8 075004
9 128710
10 128753
11 128751
12 128759
13 128638
128645
* Top assembly includes the following consumables (See page 5-6 for details of consumable parts):
220051
220037
220011
220048
220047
5-4
0
T100M Torch Main Body Replacement Kit
Retaining Clip
O-ring
Cap-off Sensor Replacement Kit
Cap-off Sensor Screws
T100/T100M Torch Head Repair Kit
Torch Mounting Sleeve Replacement Kit
Torch Mounting Screws
Torch Positioning Sleeve
25 ft (7.6 m) Torch Lead Replacement Kit
35 ft (10.7 m) Torch Lead Replacement Kit
50 ft (15.2 m) Torch Lead Replacement Kit
ETR Repair Kit (Regional Repair Centers only)
Torch Mounting Kit (for reassembly after installation)
Swirl Ring
Electrode
Nozzle
Retaining Cap
Shield
Quantity
1
1
1
1
2
1
1
3
1
1
1
1
1
1
1
1
1
1
1
