D4T/D4R

Parts and Accessories

Transmitter Power Supples
• Lectrosonics DCR15/1A6U
Switching power supply with 60320 universal
socket on housing and locking plug; 90-240 VAC,
50/60 Hz input; 15 VDC, 1.6 A max. output (regu-
lated), 18 W. (Includes 21499 AC power cord)
• Lectrosonics PS70
Switching power supply with 60320 universal sock-
et on housing and non-locking plug; 100-240 VAC,
50/60 Hz, 1.6 A (max) input; 13.8 VDC, 2.8A, 40 W
(max) output. (Includes 21499 AC power cord)
14
Receiver Power Supplies
• Lectrosonics CH20
Transformer power supply with a locking power
output plug and 2-pin AC input plug; 115 VAC
input, 12V DC regulated output; 500 mA max.
• Lectrosonics DCR15/1A6U
Switching power supply with 60320 universal
socket on housing,; 90-240 VAC, 50/60 Hz input;
15 VDC, 1.6 A max. output (regulated), 18 W. (In-
cludes 21499 AC power cord)
• Lectrosonics PS70
Switching power supply with 60320 universal
socket on housing, 100-240 VAC, 50/60 Hz, 1.6 A
(max) input; 13.8 VDC, 2.8A, 40 W (max) output.
(Includes 21499 AC power cord)
AC Power Cord
• Lectrosonics 21499 Power Cord. NEMA 5-15 plug
(USA); for use with PS70 and DCR15/1A6U
Not for use with
D4T transmitter
