Panasonic R410A Service Manual

R410a inverter
Hide thumbs

Advertisement

Table of Contents

TECHNICAL DATA

&

SERVICE MANUAL

4-Way Cassette
Ducted
■ R410A Models
Model No.
Type Indoor Units Type
U1
4-Way Cassette
E1
Ducted
Outdoor Units
Type
Type
Single Split
(1-phase)
PE1
Single Split
(3-phase)
8546484931000
60
71
S-60PU1R5
S-71PU1R5
S-60PE1R5
S-71PE1R5
60
71
U-60PE1R5
U-71PE1R5
Outdoor Unit
100
125
S-100PU1R5
S-125PU1R5
S-100PE1R5
S-125PE1R5
100
125
U-100PE1R5
U-125PE1R5
U-100PE1R8
U-125PE1R8
REFERENCE NO.
140
S-140PU1R5
S-140PE1R5
140
U-140PE1R5
U-140PE1R8
SM830210-00
