FOR YOUR sAFETY - This product must be installed and serviced by a contractor who is licensed and
qualified in pool equipment by the jurisdiction in which the product will be installed where such state or
local requirements exist. The maintainer must be a professional with sufficient experience in pool equipment
installation and maintenance so that all of the instructions in this manual can be followed exactly. Before
installing this product, read and follow all warning notices and instructions that accompany this product.
Failure to follow warning notices and instructions may result in property damage, personal injury, or death.
improper installation and/or operation will void the warranty.
improper installation and/or operation can create unwanted electrical hazard which can
cause serious injury, property damage, or death.
ATTEnTiOn insTAllER - This manual contains important information about the installation,
operation and safe use of this product. This information should be given to the owner/
operator of this equipment.
Underwater large and small light
WARning
insTAllATiOn MAnUAl
Jandy Pro series
WaterColors lED lights
English
Advertisement
Table of Contents
Related Manuals for Jandy Pro Series
Summary of Contents for Jandy Pro Series
- Page 1 MAnUAl English Jandy Pro series WaterColors lED lights Underwater large and small light WARning FOR YOUR sAFETY - This product must be installed and serviced by a contractor who is licensed and qualified in pool equipment by the jurisdiction in which the product will be installed where such state or local requirements exist.
-
Page 2: Table Of Contents
Preparing the Light Fixture for Installation ..5 section 8. Twelve (12) Volt installation ..13 3.2 Installing the Light Fixture ......... 6 section 9. Exploded View and Replacement section 4. Replacing Jandy light Fixture in an Parts ..14 Existing Pool or spa ....... 6 9.1 Jandy Large WaterColors LED Light ....14 4.1... -
Page 3: Section 1. Safety Information
Page 3 Jandy Pro Series, WaterColors LED Lights Installation Manual English ® section 1. safety information iMPORTAnT sAFETY insTRUCTiOns PERTAining TO A RisK OF FiRE, ElECTRiC shOCK, OR inJURY TO PERsOns READ AnD FOllOW All insTRUCTiOns When installing and using this electrical equipment, basic safety precautions should always be followed, including the... -
Page 4: Section 2. Product Description And Model Numbers
Page 4 English Jandy Pro Series, WaterColors LED Lights Installation Manual ® section 2. Product Description and Model numbers WaterColors light Model # Voltage Amps Cord length Face Ring Material size CPLVLEDS30 Large 12 Volt AC 30 feet Stainless Steel CPLVLEDS50 Large 12 Volt AC 50 feet... -
Page 5: Section 3. Installing Jandy Light Fixture During New Construction
(5) feet of the pool must be properly electrically 16” bonded to a reliable point of grounding. Figure 1. Jandy Pro series Digital Color light The wet niche must be properly installed so that installation the top edge of the underwater light’s lens is at least 18 inches below the surface of the water in the pool. -
Page 6: Installing The Light Fixture
Page 6 English Jandy Pro Series, WaterColors LED Lights Installation Manual ® section 4. Replacing Jandy Pro installing the light Fixture series light Fixture in nOTE Perform these steps only after the electrical system requirements are met. an Existing Pool or spa Feed cord through conduit to junction box,... -
Page 7: Replacing The Light Fixture
Page 7 Jandy Pro Series, WaterColors LED Lights Installation Manual English ® The wet niche must be properly electrically Cut the cord at the Junction Box, leaving at least bonded and grounded via the No. 8 AWG ground six (6) inches of cord to make connections. -
Page 8: Section 5. Wiring Options For Controlling Jandy
It is recommended to connect one light per relay so Sky Blue each light can be controlled separately. However, up to four lights can be connected on a single relay. If there Cobalt Blue are more than four lights installed on one AquaLink RS Caribbean Blue system, ensure there is more than one auxiliary relay Spring Green available in the Power Center. Emerald Green Refer to Figures 2 and 3 to connect the Jandy Pro Series Emerald Rose Color Lights to the Power Center. Magenta CAUTiOn Violet Slow Color Splash A Ground Fault Circuit Interrupter (GFCI) must be Fast Color Splash provided for 120 volt models. The conductors on the load side of the GFCI circuit shall not occupy conduit, America the Beautiful... - Page 9 Light Clock Motor Neutral Black White JUNCTION Line GFCI Green Ground Ground 120 VAC Figure 4. Wiring the Jandy Pro series WaterColors Power Supply light to a Time Clock 120V Light Black Black White GFCI Neutral White JUNCTION 120V Ground...
-
Page 10: To Reset To The Beginning Of The Color Sequence
Page 10 English Jandy Pro Series, WaterColors LED Lights Installation Manual ® To Reset to the Beginning of the Color Table 2. light specifications sequence Jandy Pro series Fixture light Engine (PCB) Turn the light OFF, wait four (4) to five (5) seconds, then... - Page 11 Page 11 Jandy Pro Series, WaterColors LED Lights Installation Manual English ® POOL WALL POOL LIGHT SPA LIGHT ASSEMBLY SPA WA Power ASSEMBLY Niche Cord Unscrew pilot screw Power Niche and pull top of light Cord assembly away from asse...
- Page 12 Page 12 English Jandy Pro Series, WaterColors LED Lights Installation Manual ® b. While holding the fixture upright, place the glass WARning lens with the gasket on top of the fixture. Please note that the lens gasket is not symmetrical.
-
Page 13: Section 8. Twelve (12) Volt Installation
Alignment of the lens, Face Ring, housing and Clamps for WaterColors lights Reinstall the Jandy Pro Series Light into niche fixture. a. Coil the extra four (4) feet of cord around the fixture or into the base of the niche and place the light assembly into the niche. -
Page 14: Section 9. Exploded View And Replacement Parts
Pro Series, WaterColors LED Lights Installation Manual ® section 9. Exploded View and Replacement Parts Jandy Pro series large WaterColors lED light Figure 11. Jandy Pro series large WaterColors lED light Exploded View DWg # Part # Description Field Replaceable WaterColors Light Housing... -
