Hardware Installation

DVI-I Port

DVI-I
The DVI-I port is used to connect an LCD monitor.
Connect the display device's cable connector to the DVI-I port. After you plug the
cable connector into the port, gently tighten the cable screws to hold the connec-
tor in place.
BIOS Setting
Configure the display device in the Chipset menu ("North Bridge Configuration"
submenu) of the BIOS. Refer to chapter 3 for more information.
34
