Chapter 1 - Introduction

Specifications

Processor • LGA 1155 socket for:
- Intel
- Intel
- Intel
- Intel
• New microarchitecture on 32nm process technology
• Intel
• Intel
Chipset • Intel
System Memory • Two 240-pin DDR3 DIMM sockets
• Supports DDR3 1066/1333MHz
• Supports dual channel memory interface
• Supports up to 16GB system memory
• DRAM device technologies: 1Gb, 2GB and 4Gb DDR3 DRAM
technologies are supported for x8 and x16 devices, unbuf-
fered, non-ECC
• 2 PCI Express Gen 2 x16 slots (PCIe 2.0)
Expansion Slots
- 1 x16 signal and 1 x4 signal
• 2 PCI Express x1 slots (PCIe 2.0)
Graphics • Intel
• Display ports: DVI-I (RGB and TMDS signals)-ASMedia1442
• DVI and HDMI display resolution up to 1920x1200
• Supports 6 Graphics Execution Units (EUs)
• Intel
• DirectX Video Acceleration (DXVA) support for accelerating
video processing
Audio • Realtek ALC262 2-channel High Definition Audio
• DACs with 100dB SNR; two stereo DACs support 24-bit
PCM format for stereo audio playback
• ADCs with 90dB SNR; three stereo ADCs support 20-bit
PCM format for multiple input streaming
• S/PDIF audio interface
• 1 Intel W82579LM with iAMT7.0 Gigabit Ethernet Phy
LAN
(LAN1)
• 2 Intel W82574 PCI Express Gigabit Ethernet controllers
(LAN2-3)
• Integrated 10/100/1000 transceiver
• Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
• Supports wire management
• 6 Serial ATA ports
Serial ATA
- 4 SATA 2.0 ports with data transfer rate up to 3Gb/s
- 2 SATA 3.0 ports with data transfer rate up to 6Gb/s
• Integrated Advanced Host Controller Interface (AHCI) con-
troller
• Supports RAID 0/1/5/10
Core i7-2600 (3.4GHz, 95W)
® TM
Core i5-2400 (3.1GHz, 95W)
® TM
Core i3-2120 (3.3GHz, 65W)
® TM
Pentium G850
® ®
Advanced Vector Extensions (Intel
®
Turbo Boost Technology
®
Q67 Express Chipset
®
HD Graphics
®
HDMI (TMDS signal)-ASMedia1442
Clear Video Technology
®
Introduction
AVX) Instructions
®
