2
Hardware Installation

Power-on Select

To power-on via WOL after G3:
1. Set JP11 pins 2 and 3 to On.
2. Set the "After G3" field to Power Off/WOL.
3. Set the "GbE Wake Up From S5" to Enabled.
The BIOS fields are in the "South Bridge Configuration" submenu (Chipset menu)
of the AMI BIOS utility.
To power-on via AC Power:
1. Set JP11 pins 2 and 3 to On.
2. Set the "After G3" field to Power On.
28
JP11
1 2
3
1-2 On:
Power-on via power button
(default)
1
2
3
2-3 On:
Power-on via AC power; or
Power-on via WOL after G3
