BIOS Setup

PCI Express Ports Configuration

PCI Express Ports Configuration
On Board LAN2&LAN3

On Board LAN2

Enables or disables the onboard LAN.
USB Configuration
USB Configuration

All USB Devices

EHCI Controller 1
EHCI Controller 2
USB Port 0
USB Port 1
USB Port 2
USB Port 3
USB Port 4
USB Port 5
USB Port 8
USB Port 9
USB Port 10
USB Port 11
USB Port 12
USB Port 13
All USB Devices
Enables or disables all USB devices.
EHCI Controller 1 and EHCI Controller 2
These fields are used to enable or disable Enhanced Host Controller Interface
(USB 2.0).
72
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
