FIGURE 4-1
Note – The SAS host ports on the 2540-M2 FC controller tray are not for use and not
supported.
FIGURE 4-2
1 SAS host ports
Caution – Risk of exposure to laser radiation—Do not disassemble or remove any
part of a Small Form-factor Pluggable (SFP) transceiver because you might be
exposed to laser radiation.
34
Hardware Installation Guide • June 2011
FC Host Ports on the Controllers—Rear View
SAS Host Ports on the Controllers—SAS
2 Expansion port
