- Page 1 StorageTek SL150 Modular Tape Library System Customer Replaceable Unit Guide Part Number: E29812-01 July 2012 Submit comments about this document to STP_FEEDBACK_US@ORACLE.COM.
- Page 2 StorageTek SL150 Modular Library System Customer Replaceable Unit Guide E29812-01 Oracle welcomes your comments and suggestions for improving this book. Contact us at STP_FEEDBACK_US@ORACLE.COM. Please include the title, part number, issue date, and revision. Copyright © 2012, Oracle and/or its affiliates. All rights reserved. This software and related documentation are provided under a license agreement containing restrictions on use and disclosure and are protected by intellectual property laws.
-
Page 3: Table Of Contents
Table of Contents List of Figures .......................... 5 Preface ............................7 Access to Oracle Support ......................7 Product Overview ........................9 Class 1 Laser Product Notice ....................11 Library Status Indicators ......................11 Customer Replaceable Units ..................... 12 CRU Indicators and Controls ....................12 Preparations ........................... - Page 4 Robot Module ........................36 To Remove the Robot ......................36 To Replace the Robot ......................39 Expansion Module Chassis ....................40 To Remove an Expansion Module ..................40 To Replace the Expansion CRU Chassis ................44 Base Module (Module 1) Chassis ..................49 To Remove the Base Module (Module 1) Chassis ..............
-
Page 5: List Of Figures
List of Figures FIGURE 1-1 StorageTek SL150 Base and One Expansion Module ............. 9 FIGURE 1-2 Remote Management Interface ................... 10 Library Status Indicators (Front Control Panel) ............11 FIGURE 1-3 FIGURE 2-1 SL150 Remote Management Log In Dialog ..............16 FIGURE 3-1 CRU Locations (Rear View of SL150 Base Module and Expansion Modules) .... - Page 6 6 SL150 CRU Guide July 2012...
-
Page 7: Preface
Preface This guide is intended for anyone involved with removing and replacing customer replaceable units (CRUs) of Oracle’s StorageTek SL150 Modular Tape Library System. Access to Oracle Support Oracle customers have access to electronic support through My Oracle Support. For information, visit http://www.oracle.com/support/contact.html or visit... - Page 8 Access to Oracle Support 8 SL150 CRU Guide July 2012...
-
Page 9: Product Overview
Product Overview Oracle’s StorageTek SL150 Modular Tape Library System is a rack mounted automated tape library with a capacity of 30 to 300 tape cartridges (tapes) with 1 to 20 half-height LTO Ultrium Fibre Channel (FC) or Serial Attached SCSI (SAS) tape drives (see FIGURE 1-1). -
Page 10: Figure 1-2 Remote Management Interface
The library can be expanded from one to ten modules. A 2U expansion module can be added to the library to provide an additional capacity of 30 tapes and up to two tape drives. Expansion modules are designated Module 2 through Module 10. Modules have two 15-cartridge magazines, have slots for up to two tape drives, and slots for up to two power supplies. -
Page 11: Class 1 Laser Product Notice
Class 1 Laser Product Notice The front control panel is also used to perform basic initialization setup (defining a default administrator password, setting the library date and time, and performing network configuration of Port 1). Additional library management functions are performed by the administrator using the remote interface. The library can be divided into a maximum of two partitions with each having a bridged tape drive in the base module. -
Page 12: Customer Replaceable Units
Customer Replaceable Units Customer Replaceable Units The following is a list of customer replaceable units (CRUs) in the SL150 Modular Tape Library: • Front control panel • Tape cartridge magazines • Robot • Tape drive • Power supply • Expansion module controller •... - Page 13 Customer Replaceable Units Port 1 activity (FC and SAS tape drives) Port 2 activity (SAS tape drive only) Encryption status Encryption reset: a push button switch to reset the tape drive to a default IP address. Module Controller (see FIGURE 3-18 on page 35): Fault: a fault anywhere in the module controller (KLE card) triggers the fault LED and turns off the OK LED for that specific controller (a library can have up to nine...
- Page 14 Customer Replaceable Units 14 SL150 CRU Guide July 2012...
-
Page 15: Preparations
Preparations Electrostatic Discharge Be aware of the precautions needed when handling parts. A discharge of static electricity from a finger or other conductor might damage static-sensitive devices. This type of damage may reduce the life expectancy of the product. Electrostatic Discharge Prevention •... -
Page 16: Figure 2-1 Sl150 Remote Management Log In Dialog
SL150 Remote Interface You access the remote interface by entering the library hostname or IP address in a supported web browser. The login dialog is shown in FIGURE 2-1. Note the Help link in the upper right of the screen. Refer to the user’s guide (http://docs.oracle.com) or the Help system to gain familiarity before attempting any removal or replacement action. -
Page 17: Removal And Replacement
Removal and Replacement FIGURE 3-1 shows the rear of an SL150 library where the robot, tape drive(s), power supplies, and module controller customer replaceable units (CRUs) are located. Most of the CRU removal activity involves cable disconnection, release of a latch or loosening of captive screws, and the extraction of the CRU. -
Page 18: Problem Determination
Problem Determination Problem Determination This guide assumes that the library problem has been isolated and the necessary replacement part is available. However, if the problem has not been determined; use the troubleshooting information in the user’s guide (http://docs.oracle.com) or the Help system of the SL150 remote interface (see FIGURE 2-1 on page 16). -
Page 19: To Set The Library Online
Common Procedures FIGURE 3-3 Offline Confirmation Illustration Legend: 1. Confirmation Dialog Box (OK Button) ▼ To Set the Library Online 1. Log in to the SL150 remote interface using your browser (see FIGURE 2-1 on page 16). 2. Move the cursor to the library state control in the upper right of the screen (see FIGURE 3-2 on page 18). -
Page 20: To Enable The Locate Light
Common Procedures ▼ To Enable the Locate Light 1. Log in to the SL150 remote interface using your browser (see FIGURE 2-1 on page 16). 2. Click the locate icon in the upper left of the screen (see FIGURE 3-4). 3. -
Page 21: To Remove A Tape Cartridge Magazine
Common Procedures FIGURE 3-5 Tape Magazine Illustration Legend: 1. Tape Slots in Magazine (Five Columns and Three Rows). ▼ To Remove a Tape Cartridge Magazine The following procedure relies on the SL150 remote interface. This procedure is intended only for removal of a magazine while the library is operational. This procedure is not intended as a preparation step for the removal of a failed library module. -
Page 22: Figure 3-6 Magazine Actions
Common Procedures 5. Pull the magazine free of the module and set it aside. FIGURE 3-6 Magazine Actions Illustration Legend: 1. Magazine Control (Unlatch) FIGURE 3-7 Magazine Unlatch Confirmation Illustration Legend: 1. Confirmation Dialog Box (OK Button) 22 SL150 CRU Guide July 2012... -
Page 23: To Replace A Tape Cartridge Magazine
Hot Swappable CRUs ▼ To Replace a Tape Cartridge Magazine Caution – Although the magazine contains cartridge retention springs, use care when holding or moving the magazine to avoid unseating or dropping cartridges. 1. Orient the magazine with the cartridge slots facing toward the center of the module. -
Page 24: To Remove The Drive Tray
Hot Swappable CRUs • The base module bottom drive for Partition 2 (magazines on the right side of the library, as viewed from the front). Note – Library elements such as the mailslot, robot, and reserved cells are shared by the partitions in a library. Bridge drive removal results in loss of host connectivity. -
Page 25: To Replace The Drive Tray
Hot Swappable CRUs d. Click OK in the confirmation dialog box. The physical LED at the rear of the drive tray lights to indicate the drive is ready for removal. 5. Remove the drive tray: a. Access the back of the library (open the rear door of the rack, if applicable). b. -
Page 26: Power Supply
Hot Swappable CRUs Note – Handle the drive tray by the rear corners (close to the thumbscrews) and the bottom of the tray. Avoid contact with the top cover of the actual tape drive. 3. Replace the drive tray: a. Grasp the rear corners of the drive tray. b. -
Page 27: Figure 3-10 Power Supply Cru
Hot Swappable CRUs FIGURE 3-10 Power Supply CRU Illustration Legend: 1. Power Supply Indicators 2. Power Supply Latch ▼ To Remove the Power Supply 1. Disconnect the power cord from the defective power supply (see FIGURE 3-1 on page 17). 2. -
Page 28: Other Crus
Other CRUs Note – Go to “Power System Behavior” on page 51 if the indicator is not active. Other CRUs The following procedures are for CRUs that require you to remove power from the library: • Robot • Module Controller •... -
Page 29: Figure 3-11 Power Down Library
Other CRUs b. Tap the Prepare the Robot for removal box. c. Tap OK. d. Follow on-screen prompts (for example, instructions to lock the robot). FIGURE 3-11 Power Down Library Illustration Legend: 1. Power Down Library Command FIGURE 3-12 Prepare the Robot for Removal Illustration Legend: 1. -
Page 30: To Remove A Cartridge Magazine Manually
Other CRUs ▼ To Perform a Forced Power-Down 1. Quiesce the host application to prevent disruption of active storage operations. 2. (Optional) Enable the locate library indicator (see “To Enable the Locate Light” on page 20). 3. Remove power from the library using one of the following methods: •... -
Page 31: Front Control Panel
Other CRUs FIGURE 3-13 Magazine Release Front Control Panel The front control panel is located on the base module. FIGURE 3-14 shows the back side of the panel with identification of the upper tabs, the circuit card jack, and the latches at the side of the panel. -
Page 32: Figure 3-15 Front Control Panel Side View
Other CRUs ▼ To Remove the Front Control Panel 1. Power off the library (see “To Perform a Forced Power-Down” on page 30). 2. Remove both cartridge magazines from the base module (see “To Remove a Cartridge Magazine Manually” on page 30). -
Page 33: Figure 3-16 Front Control Panel Jack
Other CRUs FIGURE 3-16 Front Control Panel Jack ▼ To Replace the Front Control Panel 1. Remove the replacement front control panel from its packaging. Caution – ESD damage. Do not touch any exposed electronic components, cables, or contacts. 2. Grasp the panel by the plastic housing and raise it to the base module. 3. -
Page 34: Figure 3-17 Front Control Panel Slots In Base Module
Other CRUs FIGURE 3-17 Front Control Panel Slots in Base Module Illustration Legend: 1. Slots in Base Module Chassis 34 SL150 CRU Guide July 2012... -
Page 35: Module Controller
Other CRUs Module Controller The module controller is located in the upper right corner of modules two through ten as viewed from the rear of the library (see FIGURE 3-1 on page 17). The module controller obtains power from the expansion cable connected to a Module Output port on the base module. -
Page 36: Robot Module
Other CRUs 6. Pull the controller card out of the module slot. 7. Set the module controller on the anti-static work surface. ▼ To Replace the Module Controller 1. Remove the replacement module controller from the ESD packaging. Caution – ESD damage. Do not touch any electronic components or electrical contacts. -
Page 37: Figure 3-19 Robot Removal And Replacement
Other CRUs 3. Reposition the robot lock (loosen the thumbscrew, remove the mechanism, rotate the mechanism 180 degrees, insert the mechanism, and tighten the thumbscrew). Note – Make sure the locked padlock icon is visible (see FIGURE 3-20 on page 38). -
Page 38: Figure 3-20 Bullwheel Gear And Robot Lock
Other CRUs ▼ To Manually Retract the Robot Note – This procedure is performed if the robot could not be parked by using the power-down procedure 1. Remove the top drive tray from the base module (see “Drive Tray Assembly” on page 23). -
Page 39: To Replace The Robot
Other CRUs 3. Cut the front suspension cables. The Z platform should settle to the floor of the bottom module. 4. Remove the library floor panel (see Step 4 “To Remove an Expansion Module” on page 40 FIGURE 3-23 on page 42). -
Page 40: Expansion Module Chassis
Other CRUs Expansion Module Chassis The CRU for modules two through ten is shown in FIGURE 3-22. You must transfer cartridge magazines, tape drives, tape drive fillers, power supplies, power supply fillers, and the module controller from the failed module to the CRU, as applicable. FIGURE 3-22 Additional Module CRU Illustration Legend: 1. - Page 41 Other CRUs 5. Disconnect cables and cords at the modules: a. Disconnect the cable from the jack at each affected expansion module controller. b. Open the hook and loop strap, extract all cables and cords, then close the hook and loop strap. c.
-
Page 42: Figure 3-23 Library Floor Panel
Other CRUs FIGURE 3-23 Library Floor Panel Illustration Legend: 1. Floor Thumbholds 42 SL150 CRU Guide July 2012... -
Page 43: Figure 3-24 Tape Drive Filler
Other CRUs ▼ To Remove the Drive Filler 1. Loosen the thumbscrew on each side of the tape drive filler. 2. Grasp the captive screws and pull the filler toward you. 3. Remove the filler from the drive slot and set it aside. You will install the filler in the CRU at a later time. -
Page 44: To Replace The Expansion Cru Chassis
Other CRUs ▼ To Remove the Power Supply Filler 1. Grasp the release latch then push the left side of the latch toward the center of the filler. 2. Pull the filler toward you. 3. Remove the filler from the power supply slot and set it aside. You will install the filler in the CRU at a later time. - Page 45 Other CRUs 3. To seat the module: a. Lower the top front edge of the expansion module while slowly pushing it toward the library. b. Take care to avoid any contact between the expansion module internal vertical flange and the bottom edge of the library module (see FIGURE 3-26 on page 46).
-
Page 46: Figure 3-26 Avoid Contact With The Operator Panel
Other CRUs FIGURE 3-26 Avoid Contact with the Operator Panel Illustration Legend: 1. Flange (Short Section) 2. Internal Vertical Flange 3. Flange (Long Section) FIGURE 3-27 Module Alignment 46 SL150 CRU Guide July 2012... - Page 47 Other CRUs FIGURE 3-27 Module Alignment (Continued) Illustration Legend: 1. Alignment Tab 2. Slot ▼ To Install the Drive Filler 1. Position the tape drive filler with the spring fingers facing up. 2. Grasp the captive screws and guide the filler into the tape drive slot. 3.
-
Page 48: Figure 3-28 Floor Tab
Other CRUs FIGURE 3-28 Floor Tab Illustration Legend: 1. Floor Slot 2. Floor Tab FIGURE 3-29 Floor Latching Tab Illustration Legend: 1. Floor Clip 48 SL150 CRU Guide July 2012... -
Page 49: Base Module (Module 1) Chassis
Other CRUs FIGURE 3-29 Floor Latching Tab (Continued) 2. Floor Base Module (Module 1) Chassis The base module CRU is shown in FIGURE 3-30. You must transfer the cartridge magazines, front control panel, tape drive(s), tape drive filler, power supply, power supply filler, and the robot from the defective base module to the CRU. -
Page 50: To Replace The Base Module (Module 1) Chassis
Other CRUs Note – Includes removal of Ethernet cable and the expansion cable(s). Set the expansion cable(s) aside. d. Tape drives (see “To Remove the Drive Tray” on page 24). e. Tape drive filler (see “To Remove the Drive Filler” on page 43). -
Page 51: Power System Behavior
Power System Behavior 5. Install the library floor in the bottom module (see “To Install the Floor” on page 47). 6. Install cartridge magazines (see “To Replace a Tape Cartridge Magazine” on page 23) in all modules. 7. Align, dress, and secure cables in the hook and loop straps. 8. -
Page 52: To Power-On The Library
CRU Return A controlled powered-down is performed from the SL150 remote interface or physical library power button (the touch screen GUI is also involved). If power is lost after a controlled power-down, the BIOS resets to power on for about 4 seconds when AC power is restored. -
Page 53: Figure 3-32 Home Screen
CRU Return FIGURE 3-32 Home Screen Illustration Legend: 1. Library Health Removal and Replacement 53 July 2012... - Page 54 CRU Return 54 SL150 CRU Guide July 2012...
-
Page 55: Startup
Startup The SL150 library is typically started up when power is applied (the power cord is plugged in or the external power is switched on). If the library was manually powered down (from the front panel power switch or the shutdown function of the remote management interface), pressing the front panel power switch starts the library. - Page 56 56 SL150 CRU Guide July 2012...
-
Page 57: Drive Firmware
Drive Firmware This appendix provides instructions to determine the current drive firmware version, and download firmware from MyOracleSupport.com. ▼ To Determine the Current Drive Firmware Version 1. Login to the SL150 remote interface. 2. Determine the current firmware version: a. Click Drives in the navigation area on the left side of the screen. b. -
Page 58: Download Firmware From Myoraclesupport
▼ Download Firmware from MyOracleSupport 1. Use a web browser and connect to https://support.oracle.com (My Oracle Support). 2. Click Register to create an account, if applicable. 3. Sign in. 4. Click the Patches & Updates tab. 5. Click the Product or Family (Advanced) link in the Search tab. 6. -
Page 59: Library Self-Test
Library Self-Test The self-test moves a diagnostic cartridge from an origination point to a destination point in an offline library. The point can be a reserved slot, a storage slot, a tape drive, or a mailslot. There are two types of self-test. The Basic Self Test performs six moves. The Full Self Test preforms the moves of the basic test plus moves to all open storage slots and installed tape drives. -
Page 60: To Finish The Self Test
Note – The library map has visual indications of cartridge movement from a slot to the robot and to a destination (tape drive, mailslot, or a cartridge slot). 7. Verify successful test completion. FIGURE C-1 Self Test Commands Illustration Legend: 1. - Page 61 c. Grasp the diagnostic tape and pull it out of the slot. d. Push the Mailslot fully into the base module. 3. Set the library to the Online state. 4. Log out from the remote interface if you will not be performing other operations.
- Page 62 62 SL150 CRU Guide July 2012...
-
Page 63: Glossary
Glossary This glossary defines terms and abbreviations in this publication. Some of the definitions are taken from other glossaries. The letters in the parentheses that follow some definitions indicate the source of the definition: (A) The American National Standard Dictionary for Information Systems, ANSI X3.172- 1990, copyright 1990 by the American National Standards Institute (ANSI). - Page 64 base module The smallest, fully functional library consisting of the base chassis with the midplane, robot, front control panel, mailslot, one or two power supplies, up to two half-height LTO Ultrium tape drives, left magazine, and right magazine. cartridge A storage device that consists of magnetic tape on a supply reel in a protective housing.
- Page 65 encryption The process of changing data into a form that cannot be read until it is deciphered, protecting the data from unauthorized access and use. Ethernet A local-area, packet-switched network technology. Originally designed for coaxial cable, it now also runs over shielded, twisted-pair cable. Ethernet is a 10 or 100 Megabytes-per-second LAN.
- Page 66 An activity in which a robot obtains a cartridge from a slot or drive. gripper The portion of the hand assembly that grasps and holds a cartridge. Graphical user interface. Software that allows the user to control the device through visual screens.
- Page 67 initialization The operations required for setting a device to a starting state, before the use of a data medium, or before implementation of a process. (T) interface Hardware, software, or both, that links systems, programs, or devices. (IBM) internet protocol (IP) A protocol used to route data from its source to its destination in an Internet environment.
- Page 68 mailslot A plastic and metal assembly located in the upper right corner of the base chassis used to enter tapes into the library and to remove tapes from the library. Previous StorageTek libraries called this a CAP (Cartridge Access Port). midplane A card mounted in the base chassis or expansion chassis that is behind the tape slots and in front of the tape drives.
- Page 69 port A specific communications end point within a host. A port is identified by a port number. (IBM) (2) In Fibre Channel, an access point in a device where a link attaches. An activity in which a robot places a cartridge into a slot or drive. power supply An AC to DC power supply that mounts into the rear of a module Module (1–10).
- Page 70 switch In Fibre Channel technology, a device that connects Fibre Channel devices together in a fabric. tape Also known as cartridge, tape cartridge, tape volume, volume, or cassette. tape cartridge A container holding magnetic tape that can be processed without separating the tape from the container.
- Page 71 Z mechanism The robotic assembly mounted at the back of the robot that raises and lowers the arm. The Z mechanism includes a motor, gears, the bullwheel, and the wires and pulleys that hold the arm. As the motor turns, the bullwheel rotates and extends or retracts the wires to lower or raise the arm.
- Page 72 72 SL150 CRU Guide July 2012...
-
Page 73: Index
Index boot up 55 indicator CRU description 12 library system 11 cartridge magazine description 9, 20 manual removal 30 laser removal 21 caution 17 replacement 23 notice 11 caution radiation exposure 17 product 11 class 1 laser product 11 library control interface 9 indicator 12 power down 28... - Page 74 replacement 47 drive 47 removal 27 power supply 47 replacement 27 floor 47 power system behavior 51 front control panel 33 product description 9 module controller 36 power supply 27 robot module 39 robot module removal manual disengagement 38 cartridge magazine 21 manually retract robot 38 cartridge magazine, manual 30 park robot 29, 36...
