FIGURE 1-1
Expansion trays
Controller tray
* In-band management is also supported.
Sun Storage 2500-M2 Arrays Connection Example Using Fibre Channel
Ethernet out-of-band*
Redundant Fibre Channel
FC switch
Local
management host
FC switch
Remote
management host
Chapter 1
Installing Sun Storage 2500-M2 Arrays
Data hosts
Host 1
Host 2
Host 3
Host 4
Host 5
3
