Sun Storage 2500-M2 Arrays
Getting Started Guide
This document provides an overview of the installation procedure for Oracle's Sun Storage 2500-M2 Arrays,
including:
Sun Storage 2540-M2 array (controller tray with Fibre Channel host connectivity)
■
Sun Storage 2530-M2 array (controller tray with SAS-2 host connectivity)
■
Sun Storage 2501-M2 array (expansion tray)
■
For detailed information, have the Sun Storage 2500-M2 Arrays Hardware Installation Guide available as you go
through the steps in this document.
Additional documentation is listed in the section
documentation web site:
http://www.oracle.com/technetwork/documentation/oracle-unified-ss-193371.html
Sun Storage Common Array Manager
Oracle's Sun Storage Common Array Manager (CAM) software is a key component for the initial configuration
and operation of Sun Storage 2500-M2 Arrays hardware. It is installed on a management host cabled to the array
via out-of-band Ethernet (cables for this connection are provided). Note: In-band management is also supported.
To download and get started with CAM, review the latest Sun Storage Common Array Manager Quick Start Guide.
CAM documentation can be found here:
http://www.oracle.com/technetwork/documentation/disk-device-194280.html
Note –
It is recommended to begin the download process now so that the software is ready for installation when
hardware installation is complete.
Before You Begin
Review the following documents before starting the installation:
• Important Safety Information for Sun Hardware Systems
• Sun Storage 2500-M2 Arrays Safety and Compliance Manual
"Documentation for This Product"
• Sun Storage 2500-M2 Arrays Hardware Release Notes
• Sun Storage 2500-M2 Arrays Site Preparation Guide
and available at the Oracle
1
Advertisement
Table of Contents
Related Manuals for Sun Oracle 2500-M2
Summary of Contents for Sun Oracle 2500-M2
- Page 1 Oracle’s Sun Storage Common Array Manager (CAM) software is a key component for the initial configuration and operation of Sun Storage 2500-M2 Arrays hardware. It is installed on a management host cabled to the array via out-of-band Ethernet (cables for this connection are provided). Note: In-band management is also supported.
- Page 2 Review Contents of the Ship Kit shows the components of the controller tray ship kit for the Sun Storage 2540-M2 array, Sun Storage FIGURE 1 2530-M2 array, and Sun Storage 2501-M2 array expansion tray. Note the following: AC or DC power cables are included in the ship kit, depending on the configuration ordered. ■...
- Page 3 Install the Tray in the Cabinet and Connect Power Cables The following procedure provides an overview of installing a controller tray or expansion tray into the cabinet. Consult the Hardware Installation Guide for further details. Note – Airflow through the tray is front-to-back. For proper ventilation, allow 30 in (76 cm) clearance in front of the cabinet and 24 in (61 cm) clearance behind the cabinet.
- Page 4 Review Rear Panel Note: AC power connectors and switches shown. DC configuration is available. See Hardware Installation Guide for more information. Controller Tray Rear View FIGURE 4 Callout Description: 2540-M2 and 2530-M2 Controller module A Serial port Ethernet ports SAS host ports (Not used on 2540-M2) Seven-segment display Fibre Channel host ports...
- Page 5 Connect Controller and Expansion Trays shows recommended expansion cabling for one, two, and three expansion trays. See the Hardware FIGURE 6 Installation Guide for more information. Expansion Tray Cabling Configurations FIGURE 6 Connect Data Hosts shows sample host connection configurations for one host in a direct topology, two hosts in a direct FIGURE 7 topology, and two hosts in a Fibre Channel switch topology.
- Page 6 During initial array registration, you are prompted to register with the Auto Service Request (ASR) service. It is highly recommended that you register with ASR so that Support can respond appropriately to your needs. Documentation for This Product Additional documentation for Sun Storage 2500-M2 Arrays is available at: http://www.oracle.com/technetwork/documentation/oracle-unified-ss-193371.html Review safety information...
