User Menu Structure

5. User Menu Structure
The User menu enables configuring the basic user settings, such as setting the
date and time and changing user codes. You can define one Master user and
up to twenty additional users, each with an individual code.
Settings marked with an "M" can be accessed by the Master user only, and
appear only if the master code is entered.
If the master code has not been specified and the installer has set the zone
bypass to Off, the User menu is unavailable to regular users.
To enter the User menu:
1. On the panel, press Menu repeatedly until the screen displays
2. Press Enter.
3. Enter the Master user code (the default code is 1234) and press Enter.
The system is locked out for 90 seconds after entering 5 wrong codes.
The User menu options are displayed in Table 7:
Select
(M) Edit Master
Code
(M) User Codes
Authorization Code Specify the code that is used to configure the system's settings
(M) Set Date & Time Set the Time & Date, as specified in Section 9.5.
(M) Date & Time
Format
Zone Bypass
22

Table 7: User Menu Options

To
Change the master code (see Section 9.2).
Specify user codes 1 through 20.
If the user code exists, you can edit the code or delete it by
pressing # (see Section 9.3).
with the remote programming software HR-P02. The default
code is 1234.
Specify the format in which the time is specified: 24 hour
format or AM/PM. By toggling between the two using the
Menu button.
Specify the format in which the date is specified: DD-MM-YY or
MM-DD-YY (see Section 9.6)
Enables you to arm the system by bypassing/un-bypassing
selected zones (see Section 9.7).
This option is enabled if manual bypass has been enabled by the
installer.
Note: Zone bypass can be triggered only if the zone was
enrolled.
User
.
HLX-40 User Manual
