DEVISES AND ATTACHMENTS
Model Part No.
● Chain-off thread trimming device
One-touch type tape cutter
MAT-039003A0
and chain-off thread
T039
trimming device
MAT-039004A0
(electromagnetic type)
Automatic tape cutter
MAT-040005A0
+ chain-off thread
MAT-040006A0
trimming device
T040
(number-off-stitch
MAT-040005AA
control and electro-
MAT-040006AA
magnetic type)
T041 MAT-041000AB Pneumatic flat cutter
T045 MAT-045000A0 Pneumatic side cutter (for overlock machine)
● Blower-type chain-off thread suction device
MC-7A Blower-type chain-off thread suction device + cloth chips
● Pneumatic chain-off thread suction device
MC-4 Specific to chain-off thread, pedal-operated
MC-5 Specific to chain-off thread
MC-8 Pneumatic chain-off thread + cloth chips
MC-9 Function of MC-8 + auto-lifter
MC-24 Pneumatic chain-off thread + cloth chips
The aforementioned devices are not equipped with air regulator.
Please purchase the following components when you need to regulate air pressure.
PF-0552010-B0 Air regulator (F.R. unit asm.)
GMD-01080000 2 Fixing screw for F.R. unit asm.
F1021-003-000 Tube connector (male)
One-touch connector
GAS-12063000
Selection parts instead of the tube connector
● Auto-lifter
AK32 GAK-320000A0 Pneumatic type (knee-operated)
AK49 GAK-490000A0 Pneumatic type (pedal-operated)
AK101 GAK-A01000A0 Pneumatic type (for servomotor)
Model Part No.
● Gathering device
Swing-type upper-cloth gathering device
S167 MAS-167000A0
(interlocked with pedal)
● Blind hemming device
L121 MAL-121000A0 Blind stitch hemming attachment
● Piping folder
M056 MAM-0560J0A0 Piping folder
M075 MAM-0750J0A0 Piping folder (to be used with knit tape)
M076 MAM-0760N0A0 Ready-made piping folder
M077 MAM-0770M0A0 Piping folder for gathering
Piping folder upper-cloth gathering
MAM-2220M0A0
(finished width 12mm, tape width 26mm)
M222
Piping folder upper-cloth gathering
MAM-2220J0A0
(finished width 9mm, tape width 20mm)
M224 MAM-2240N0A0 Ready-made piping folder for upper-cloth gathering
● Guide, Ruler
H153 MAH-153000A0 Cloth edge guide ruler (for overlock machine)
H154 MAH-154000A0 Cloth edge guide ruler (for safety stitch machine)
Q141 MAQ-141000B0 Tape guide
Description
For 110, 115, 220, 240V
For 220, 380, 415, 440V
For 110, 115, 220, 240V
For semi-
sunken type
For 220, 380, 415, 440V
For 110, 115, 220, 240V
For fully-
sunken type
For 220, 380, 415, 440V
Description
[Reference]
Combination table of "chain-off thread suction device" and
"auto-lifer" which correspond to "chain-off thread trimming device".
Chain-off Chain-off
thread thread
trimming suction
device device
MC-7A AK101
T039 MC-8 AK101
MC-9
(MC-9 is equipped with auto-lifter.)
MC-7A AK32
T040 MC-5 AK32
MC-24 AK32
MC-7A AK101
T041
or MC-8 AK101
T045
MC-9
(MC-9 is equipped with auto-lifter.)
Feature
The attachment opens with the presser foot pedal. This facilitates material
setting on the machine. Furthermore, knee-control type differential-feed
adjusting device is built in the attachment. It controls a differential-feed ratio
as desired, thereby enabling the operator to make beautiful gathers.
A ruler used for blind hemming in knits
This piping folder makes a piping first, then turns up the tape.
This attachment can be used for both "cotton bias tape with gimp" and "knit tape".
The operation mode can be changed over with a fingertip control.
The dimension of ready-made tapes can be adjusted within the range of 8 to 13mm.
The attachment makes gathers on the lower fabric while making decorative piping.
This folder is to be used together with upper-cloth gathering device S167.
Gimp size that can be used is 2 to
This folder is to be used together with upper-cloth gathering device S167.
Tape, of which width is 8 to 18mm, can be used.
A swing type edge guide.
This attachment is used attached on the machine head (face plate).
It is used for tapes with the width of 7mm or less.
MO-6900R Series (September, 2003) 3/3
Auto-lifter
(JUKI servomotor)
(JUKI servomotor)
(any motor will do)
(any motor will do)
(any motor will do)
(JUKI servomotor)
(JUKI servomotor)
2.5mm.
