DEVISES AND ATTACHMENTS
Model Part No.
● Chain-off thread trimming device
One-touch type tape cutter
MAT-039001A0
and chain-off thread
T039
trimming device
MAT-039002A0
(electromagnetic type)
Automatic tape cutter
MAT-040001A0
+ chain-off thread
MAT-040002A0
trimming device
T040
(number-off-stitch
MAT-040001AA
control and electro-
MAT-040002AA
magnetic type)
T041 MAT-041000A0A Pneumatic flat cutter
T042 MAT-042000A0 Pneumatic side cutter (for overlock machine)
● Blower-type chain-off thread suction device
MC-7A Blower-type chain-off thread suction device + cloth chips
● Pneumatic chain-off thread suction device
MC-4 Specific to chain-off thread, pedal-operated
MC-5 Specific to chain-off thread
MC-8 Pneumatic chain-off thread + cloth chips
MC-9 Function of MC-8 + auto-lifter
MC-24 Pneumatic chain-off thread + cloth chips
The aforementioned devices are not equipped with air regulator.
Please purchase the following components when you need to regulate air pressure.
PF-0552010-B0 Air regulator (F.R. unit asm.)
GMD-01080000 2 Fixing screw for F.R. unit asm.
F1021-003-000 Tube connector (male)
One-touch connector
GAS-12063000
Selection parts instead of the tube connector
● Auto-lifter
AK32 GAK-320000A0 Pneumatic type (knee-operated)
AK49 GAK-490000A0 Pneumatic type (pedal-operated)
AK101 GAK-A01000A0 Pneumatic type (for servomotor)
Model Part No.
● Gathering device
Swing-type gathering device
S159 MAS-159000A0
(interlocked with pedal / for safety stitch machine)
Swing-type gathering device
S160 MAS-160000A0
(interlocked with pedal / for overlock machine)
Swing-type gathering device
S161 MAS-161000A0
(manual-lever operated / for safety stitch machine)
Swing-type gathering device
S162 MAS-162000A0
(manual-lever operated / for overlock machine)
● Blind hemming device
L121 MAL-121000A0 Blind stitch hemming attachment
● Piping folder
M056 MAM-0560J0A0 Piping folder
M075 MAM-0750J0A0 Piping folder (to be used with knit tape)
M076 MAM-0760N0A0 Ready-made piping folder
M077 MAM-0770M0A0 Piping folder for gathering
● Guide, Ruler
H153 MAH-153000A0 Cloth edge guide ruler (for overlock machine)
H154 MAH-154000A0 Cloth edge guide ruler (for safety stitch machine)
Q141 MAQ-141000B0 Tape guide
● Feller, Binder
K006 MAK-00601000 Upturn feller
N067 MAN-0670D0A0 Reinforcement tape attachment binder (finished width: 4mm) This binder binds the edge of a pocket bag while cutting round its periphery.
MO-6900S Series (September, 2003) 4/4
Description
For 110, 115, 220, 240V
For 220, 380, 415, 440V
For 110, 115, 220, 240V
For semi-
sunken type
For 220, 380, 415, 440V
For 110, 115, 220, 240V
For fully-
sunken type
For 220, 380, 415, 440V
Description
[Reference]
Combination table of "chain-off thread suction device" and
"auto-lifer" which correspond to "chain-off thread trimming device".
Chain-off Chain-off
thread thread
trimming suction
device device
MC-7A AK101 (JUKI servomotor)
T039 MC-8 AK101 (JUKI servomotor)
MC-9 (MC-9 is equipped with auto-lifter.)
MC-7A AK32 (any motor will do)
T040 MC-5 AK32 (any motor will do)
MC-24 AK32 (any motor will do)
AK49 (Motors other than JUKI servomotors
are applicable.)
MC-7A
T041
AK101 (JUKI servomotor)
or
MC-4
T042
MC-8 AK101 (JUKI servomotor)
MC-9 (MC-9 is equipped with auto-lifter.)
Feature
The attachment opens with the presser foot pedal. This facilitates material
setting on the machine. Furthermore, knee-control type differential-feed
adjusting device is built in the attachment. It controls a differential-feed ratio
as desired, thereby enabling the operator to make beautiful gathers.
The attachment is used to perform two different processes, joining fabric
process and gathering process, at a time.
The attachment can be opened/closed by using the lever (manually operated).
The differential-feed ratio is controlled with the knee lever.
A ruler used for blind hemming in knits
This piping folder makes a piping first, then turns up the tape.
This attachment can be used for both "cotton bias tape with gimp" and "knit tape".
The operation mode can be changed over with a fingertip control.
The dimension of ready-made tapes can be adjusted within the range of 8 to 13mm.
The attachment makes gathers on the lower fabric while making decorative piping.
A swing type edge guide.
This attachment is used attached on the machine head (face plate).
It is used for tapes with the width of 7mm or less.
This feller is exclusively used with the 3C0 throat plate. It is attached on the throat plate.
Auto-lifter
