1-needle, Lockstitch Machine with Edge Trimmer
DLM-5200N
DLM-5210N
(exclusive machine for piping)
● The highly efficient lockstitch machine which assures the
consistent quality of finished seams comes with a sharp knife
capable of cutting various types of material.
The DLM-5200N series is composed of high-quality sewing
machines provided with these two main features, both of
which are designed to significantly upgrade the functions.
● The knife is designed so that the angle can be changed as
desired, allowing the knife to be easily applied to any type of
material.
● The knife can be attached by simply pressing the presser plate
on the machine arm. The knife is removed also by the
simple operation of the knob.
such as with or without knife, can be changed with ease.
● The adjustment of the needle and needle gauge can be made
by the simple change of the sub-gauges.
SPECIFICATIONS
Model name
Max. sewing speed
Max. stitch length
Needle bar stroke
Lift of the presser foot
Needle (at the time of delivery)
Hook
Max. thickness of the material to be cut
Lubrication
Lubricating oil
Weight of the machine head
WHEN YOU PLACE ORDERS
DLM5200N
Sub-gauge type
Distance between the
needle and the knife
3.2mm (1/8") standard
2.4mm (3/32")
4.0mm (5/32")
4.8mm (3/16")
6.4mm (1/4")
9.5mm (3/8")
Thus the type of stitching,
DLM-5200N
4,500rpm
5mm (normal/reverse feed)
Rolled hem
Code
Clean finish, top and bottom
D
C
E
F
H
M
30.7mm
By hand: 4mm, By knee: 10mm
DB 1 (#14), For JE: 134 (Nm90)
Automatic-lubricating full-rotary hook
4mm
Automatic
JUKI New Defrix Oil No.1 (equivalent to ISO VG7)
30kg
DLM5210N/ N01
Type of binder Code
N011
N015
DLM-5200N
DLM-5210N
Front knife type
4,000rpm
4mm (normal/reverse feed)
Finished width
N011 N015 Code
5mm A
6mm B
7mm C
9.5mm E
DLM-5200N, 5210N (September, 2003) 1/2
