Direct-drive, High-speed, Needle-feed, Lockstitch Machine
with Automatic Thread Trimmer
DLN-9010
● Thanks to the needle-feed mechanism which offers excellent
efficiency of feed, the machine ensures accurate stitch pitches
(stitch length) as well as preventing slippage of the upper cloth.
The bottom feed's locus has been improved to match the
needle feed motion, thus the machine produces beautiful
seams without stitch gathering, even when it is used for sewing
slippery and difficult-to-feed material or for handling a difficult
process.
● The needle feed mechanism is a so-called "dry type", which
does not require oiling. With this mechanism, a highly reliable
machine structure, free from oil leakage troubles, has been
achieved. The frame, which requires only a minute quantity of
lubricating oil, is structured to eliminate oil leakage.
SPECIFICATIONS
Model name
Application
Max. sewing speed
Max. stitch length
Needle bar stroke
Lift of the presser foot
Needle (at the time of delivery)
Hook
Lubrication
Lubricating oil
Distance from needle to machine arm
Size of bed
Bobbin thread winder
Micro-lifter screw
Machine head drive
Automatic reverse feed function
Power requirement/Power consumption
Total weight
WHEN YOU PLACE ORDERS
Machine head type Code
Standard S
● PSC box
PSC box
For JUS (LA) Single-phase 100 120V
For JUS General Export 3-phase
For General Export Single-phase 200 240V
For EU (CE) Single-phase 200 240V
For China Single-phase 200 240V
JUS: North America and Central and South America.
DLN-9010SS
For light- to medium-weight materials
5,000rpm
DB 1 (#11) #9 #18
For JE:134 (Nm90) Nm65 Nm110
Compact AC servomotor that is directly connected to the main shaft (direct-drive system)
Single-phase 100 120V, 200 240V, 3-phase 200 240V 650VA
The maximum sewing speed is 4,000 rpm or less in cases where the maximum stitch length is 3.5 mm or more.
DLN9010S
Application Code
For light- to
S
medium-weight materials
For heavy-weight materials H
SC910
Code
PFL S
200 240V PFL D
PFL K
PFL N
PFL U
4.5mm
33mm
By hand: 5.5mm, By knee: 15mm(max.), Auto: 10mm
Automatic-lubricating full-rotary hook
Minute-quantity lubrication to needle bar and hook
JUKI New Defrix Oil NO.1 (equivalent to ISO VG7)
300mm
517mm 178mm
Built-in the machine head
Provided as standard
Provided as standard (built-in solenoid type)
87kg
Wiper and automatic reverse feed function
Automatic reverse
Wiper
feed function
Not provided Provided
Provided Provided
Control box
Standard
Provided with built-in I/O board
● Control box provided with built in I/O board
(Code A) should be selected for the machine
head equipped with the remaining bobbin
thread detector (AE-8).
DLN-9010SS-WB/CP-160D
DLN-9010SH
For heavy weight materials
4,000rpm
DB 1 (#21) #20 #23
For JE:134 (Nm130) Nm120 Nm160
Device and
attachment
Code
Not provided
0B Auto-lifter
(pedal-driven)
WB
● Operation panel
Operation panel
IP-100B
CP-160D
Code
S
A
DLN-9010 (September, 2003) 1/2
1
Code
AK118
Code
IP100B
CP160D
