WORK CLAMP FOOT AND FEED PLATE FOR LK-1902A
Work clamp foot
13544465
Provided as
standard
LK-1902A-SS
LK-1902A-HS
17
13545660
Option
For large size
27
13547161
Option
For extra large
size
37
41.5
A finger guard is included in the presser foot.
OPERATION PANEL
● Functional settings, such as pattern numbers, enlargement/reduction
scales, swing speeds and needle thread tensions can be established
through the operation panel with ease.
● Standard sewing patterns can be assigned to pattern keys P1 to P50.
Any of the sewing patterns assigned to the P1 to P25 pattern keys can
be activated with a touch of the corresponding key.
workability is improved by assigning 25 sewing patterns that are most
frequently used to those pattern keys.
● As many as 20 different cycle sewing patterns, each of which
combines a maximum of 30 different sewing patterns, can be stored
in the memory.
● The operation panel has been installed at an angle and can be placed
at the top, bottom, right or left part of the table according to the
operator's preference.
● A large color LCD touch panel has been adopted for the display.
clear displays that allow the operator to understand operating procedures.
● The IP-200B panel can be connected to a personal computer and can store
data on SmartMedia. This allows data to be exchanged or shared among
sewing machines installed in a factory or among remote factories.
● The IP-200B panel has been provided with a process improvement
supporting feature through the indication of the operational state of the
sewing machine, and a maintenance and management feature for
indicating the needle changing timing and cleaning timing.
LK-1900A, 1901A, 1902A (September, 2003) 6/7
Feed plate Number of pattern
14143002
24.8
13545504
27.4
13545801
37
13547005
37.4
(You can choose operation panel.)
STANDARD PANEL
This means that
LK-1900A-SS/Installation of the IP-200B
(for belt-loop attaching)
17
18
19
20
21
22
22
IP-200B
It gives
