Parts List - TTI CPX200 Service Manual

PCB ASSY FRONT PANEL - (44115-0820)
Part Number Description
22226-0140 KEYSWITCH DARK GREY
22573-0056 HEADER 16 WAY STR SIL
23202-0270 RES 27R0F W25 MF 50PPM
23202-1910 RES 910RF W25 MF 50PPM
23202-2150 RES 1K50F W25 MF 50PPM
23202-3100 RES 10K0F W25 MF 50PPM
23202-3470 RES 47K0F W25 MF 50PPM
23202-4470 RES 470KF W25 MF 50PPM
23347-0140 POT 10K LIN
23347-0150 POT 10K LOG
23382-3100 RES PS/H10K CERMET MIN
23557-0658 CAP 100U 25V ELEC P2.5
23620-0246 CAP 100NK 63V P/E P5
25061-0200 LED - T1 ROUND (3MM) - RED
25061-9503 DISPLAY - 4 DIGIT LED
27164-0506 IC ULN-2803A
27231-2730 IC 74HC273
27234-5730 IC 74AC573
35555-2260 PCB - FRONT PANEL
PCB ASSY CNTL - (44115-0810)
Part Number Description
20030-0263 WASHER M3 ZPST
20038-9501 WASHER M3 SPRING
20210-0101 NUT M3 ZPST
20234-0011 SCREW M3 X 10 PNHDPZ NPST
20611-0003 BUSH POLYESTER TO220 J22-5006
20613-0006 WASHER (SIL-PAD) TO220
20661-0800 SPACER TRANSISTOR MTG TO18
20670-0130 HEATSINK PCB MTG 25MM HIGH
20670-9002 T0220 CLIP ON HEATSINK
22315-0440 FUSE 375mAT SUBMIN PCB MTG
22315-0452 FUSE 1.0AT SUBMIN PCB MTG
22573-0205 HEADER 5 WAY STRAIGHT .156P
22574-0122 SKT DIL 28 PIN
14
Position
K1,2,101,102
FOR DISPLAYS
R1-8,101-108
R21,121
R17,18,38,39,117,118,138,139
R19,31,40,119,131,140
R9,12,109,112
R20,120
VR1,2,101,102
VR4,104
VR3,103
C1,101
C2,15-19,102,115-119
LED1-4,101-104
DISP1,2,101,102
IC8,108
IC6,7,106,107
IC5,10,105,110
Position
FOR IC8/9,108/109
FOR IC8/9,108/109
FOR IC8/9,108/109
FOR IC8/9,108/109
FOR IC8,108
FOR IC8/108
FOR IC3,103
HS1,101
FOR IC10,110
FS3,4,103,104
FS1,2,101,102
PJ5,7,105,107
FOR IC11,111

Parts List
