Parts List - TTI QL II Series Service Manual

PCB ASSEMBLY – POWER – QL355
Part No. Description
20073-9801 SCREW No.4x1/4in. Plastite
20613-0026 SIL-PAD 900S 100MM X 25MM
20670-0366 HEATSINK LS01000 100MM PLAIN
20670-0367 CLIP 1 FOR TO220/TO247 H/S
22240-0150 RELAY 12V DPDT 8A
22312-0242 FUSE CLIPS PCB MTG
22315-0310 FUSE 10A ANTISURGE(T) HBC UL
22315-0451 FUSE 750mAT SUBMIN PCB MNT UL
22315-0452 FUSE 1.0AT SUBMIN PCB MTG UL
22573-0041 HEADER 2WAY STR SIL STD/GOLD
22573-0071 HEADER 5 WAY STR SIL STD
22573-0150 HEADER 20 WAY STR LATCHING
22573-0225 HEADER 5 WAY STR F/LOCK .156
22573-0226 HEADER 6 WAY STR F/LOCK .156
22573-0247 HEADER 2 WAY STR .1P F/LOCK
22573-0251 HEADER 6 WAY STR .1P F/LOCK
22573-0262 HEADER 2 WAY RT ANG F/LOCK .1P
22573-0410 HEADER 10W (2x5) BOXED
22575-0038 HEADER 6 WAY STR SIL STD
22575-0068 HEADER 14 WAY (2X7) STR SKEL
22575-0103 HEADER 16 WAY (2X8) STR SKEL
23202-3100 RES 10K0F W60 MF 50PPM
23274-0104 RES 0R22J 3W WW
23424-0443 CAP 10NZ 1KV CER D10 P5
23557-0660 CAP 2200U 16V ELEC RE2 P5
23557-0664 CAP 1000U 35V ELEC RE2 P5
23557-0770 CAP 10000U 63V ELEC LP5 P10
23620-0247 CAP 220NK 63V P/E P5
23620-0257 CAP 2U2K 100V P/E P22.5
23620-0263 CAP 220NK250VP/E 368 SER P15
23620-9007 CAP 10NK 100V P/E P5
25115-0907 DIO 1N4002 B/R
25210-0060 THYRISTOR 2N6507 TO-220
25211-0303 RECTIFIER BRIDGE 8A 200V SIL
12
Position
HEATSINKS
FOR HS1, HS2
SK1-2
FOR IC1-3,Q22,SCR1-2,BR1,Q15,Q16
RL1-2
FS1
FS1
FS4 ,FS6
FS5
LK1-3, TP1, TP5, TP2-4 (1 PIN EACH)
PJ8
PJ10-11
PJ1
PJ2
PJ6 (Rear Mount), PJ7 (REAR MOUNTED),
PJ9
PJ5/PJ13 (R/MOUNTED)
PJ4
PJ15 (REVERSE MOUNTED)
PJ3
PJ12
PJ14 ,PJ20
R3 ,R96
R26-27
C12-13
C3
C1-2
C4-5
C16-17
C9-10
C11 ,C23
C87
D20-22
SCR1-2
BR1

Parts List
