TTI CPX200 Service Manual page 17

PCB ASSY CNTL - (44115-0810) continued/...
Part No. Position
23202-4100 RES 100KF W25 MF
23202-4120 RES 120KF W25 MF 50PPM
23202-4160 RES 160KF W25 MF 50PPM
23202-4200 RES 200KF W25 MF 50PPM
23202-4750 RES 750KF W25 MF 50PPM
23202-4820 RES 820KF W25 MF 50PPM
23202-5100 RES 1M00F W25 MF 50PPM
23206-1470 RES 470RF W6 MF 50PPM
23210-3100 RES 10K0J 2W MF 250PPM
23301-0457 RES NETWK SIL 47K X 4S
23377-1470 RES PS/H 470R CF 10MM
23377-2100 RES PS/H1K0 CF 10MM
23377-2220 RES PS/H2K2 CF 10MM
23377-2470 RES PS/H4K7 CF 10MM
23377-3100 RES PS/H10K CF 10MM
23377-3220 RES PS/H22K CF 10MM
23379-2220 RES PS/H2K2 Cermet 10MM
23379-3100 RES PS/H10K Cermet 10MM
23427-0331 CAP1N0K 63V CER HI K P5
23427-0374 CAP 100PJ 100V CER N150 P2.5
23427-0384 CAP 220PK 100V CER MED K P2.5
23557-0611 CAP 47U 10V ELEC P2
23557-0612 CAP 1U0 50V ELEC P2
23557-0658 CAP 100U 25V ELEC P2.5
23557-0660 CAP 2200U 16V ELEC P5
23557-0664 CAP 1000U 35V ELEC P5
23620-0245 CAP 4N7K 63V P/E P5
23620-0246 CAP 100NK 63V P/E P5
23620-0247 CAP 220NK 63V P/E P5
23620-0249 CAP 330NK 63V P/E P5
23620-0252 CAP 2N2K 63V P/E P5
23620-0256 CAP 1U0K 63V P/E P5
23620-9007 CAP 10NK 100V P/E P5
23621-0310 CAP10NJ 400V P/E P7.5
PCB ASSY CNTL - (44115-0810) continued/...
16
Description
R18,19,86,87,118,119,186,187
R83,183
R53,153
R34,88,134,188
R14,114
R92,192
R78,178
R4,104
R1,101
RP4,104
VR5,105
VR4,104
VR6,106
VR7,107
VR16,116
VR1,101
VR8,108
VR2,3,102,103
C16,116
C3,18,103,118
C2,102
C48,50,148,150
C10,21,42,110,121,142
C25,26,36,125,126,136
C13,113
C27,29,127,129
C8,108
C1,6,11,12,14,15,17,19,20,23,28,
30-33,35, 38-40,47,49,54,101,106,111,
112,114,115, 117,119,120,123,128,
130-133, 135,138-140,147,149,154
C22,122
C46,146
C7,107
C43,51,52,143,151,152
C5,9,34,105,109,134
C44,144
