TTI CPX200 Service Manual page 21

REAR PANEL ASSY - (46912-0520)
Part No. Description
20030-0266 WASHER M4 ZPST
20037-0401 SOLDER TAG SHAKEPROOF - 4BA
20038-9502 WASHER M4 Spring
20210-0102 NUT M4 ZPST
20213-0010 CAPTIVE NUT SNU-1219-17-00
20234-0029 SCREW M4 X 12 PNHDPZ ZPST
20236-0010 SCREW M4 X 12 TAMPERPROOF
22115-0260 TRANSFORMER - CPX200
22575-0204 SKT4W .156 20AWG IDT
22575-0205 SKT5W .156 20AWG IDT
22575-0207 SKT7W .156 20AWG IDT
33331-3540 REAR PANEL PRINTED
FRONT PANEL ASSY - (46912-0510)
Part No. Description
20030-0263 WASHER M3 ZPST
20037-0247 WASHER 4BA SHK/PROOF I/T ZPST
20037-0305 WASHER 5/16in.SHK/PRF I/T ZPST
20038-9501 WASHER M3 Spring
20038-9503 WASHER M3.5 SPRING
20234-0027 SCREW M3 X 6 PNHDPZ ZPST
20657-0110 KNOB 15MM DA150 006 GREY/99
20657-0111 CAP BLK LINE C157/132 GREY 99
22040-0030 FERRITE SLEEVE APPROX 7/14/15L
22219-0050 SWITCH ROCKER DPST SOLDER LUGS
22450-0020 EYELET M3.5 (4BA) SHRD BLUE
22451-0200 SOLDER TAG 4BA
22571-0670 TERMINAL INSULATED RED
22571-0680 TERMINAL INSULATED BLACK
22571-0690 TERMINAL INSULATED GREEN
22571-0691 WASHER ALUMINIUM FOR TP2E TERM
22575-0202 SKT2W .156 20AWG IDT
22575-0207 SKT7W .156 20AWG IDT
23424-0454 CAP 10NZ 1KV CER P10
23620-0232 CAP 47NK 63V P/E P5
33331-3520 FRONT PANEL
33331-3530 OVERLAY FRONT PANEL
35331-0080 SHORTING BAR - PLATED
CASE PARTS - (51153-0901)
20
Position
TRANSFORMER, EARTH
EARTH
TRANSFORMER, EARTH
TRANSFORMER, EARTH
TRANSFORMER
EARTH
PJ9
PJ7,107
PJ1A
Position
PCB FIXING
GREEN TERMINAL
GREEN TERMINAL
PCB FIXING
TERMINALS
PCB FIXING
LLA,LLB
MAINS SWITCH
SENSE LEADS
TERMINAL
TP2
TP2
TP2
EARTH TERMINAL
PJ2,102
PJ6
CAA,CAB
CBA,CBB
