TTI CPX200 Service Manual page 20

Part No. Position
23209-5100 RES 1M00F W75 MF 100PPM
23296-0020 RES 0R01D 4 TERM 30PPM PBV
23379-1100 RES PS/H 100R Cermet 10MM
23386-0010 VARISTOR V275LA20A
23386-0030 THERMISTOR - INRUSH LIMITER 4A
23388-0030 THERMISTOR PTC 2322.661.15693
23424-0459 CAP 4N7 250V AC CER Y RATED
23556-0230 CAP 1000UM 200V ELEC
23556-0222 CAP 100U 385/400V ELEC
23556-0225 CAP 2200U 50V ELEC LOW ESR
23557-0612 CAP 1U0 50V ELEC P2
23557-0655 CAP 470U 35V ELEC P5
23557-0659 CAP 47U 25V ELEC P2
23557-0676 CAP 470U 63V ELEC P5
23620-0246 CAP 100NK 63V P/E P5
23620-0261 CAP 100NK 400V P/E
23620-9007 CAP 10NK 100V P/E P5
23684-0010 CAP 470NK 250VAC X2 P/P P27.5
23687-0010 CAP 1N0F 400V P/P AXIAL
25031-0060 DIO BYV27
25031-0070 DIO BYV29-400
25031-0080 DIO BYV32E
25117-0020 DIO 1N5401
25130-0207 DIO ZEN 15V W4
25131-0224 DIO ZEN 18V 1W3
25211-0302 BRIDGE RECTIFIER D5SB60
25211-9302 RECTIFIER BRIDGE W02G
25601-0440 TRAN MOSFET N CHAN 500V 10A
27160-0015 IC V/REG 78L15 TO92 (NS)
27168-0100 IC IR2110 MOSFET DRIVER
35555-2270 PCB - MAIN
Description
R3
R14,114
VR1,101
VDR1
RT1
PTC1,2,101,102
C6,7
C1,2
C12,112
C14,114
C22,23,25,122,123,125
C61,161
C63,163
C15,16,115,116
C19,21,24,26,27,62,119,121,124,126,
127,162
C17,18,117,118
C13,113
C5,8,9
C10,11,110,111
D5,105
D1,2,101,102
D3, 4,103,104
D6,106
D9,109
D7, 8,107,108
BR1
BR2,102
Q1, 2,101,102
IC16,116
IC1,101
19
