TTI CPX200 Service Manual page 19

PCB ASSY - MAIN (44115-0800) continued/...
Part No. Position
20611-0003 BUSH POLYESTER TO220 J22-5006
20613-0012 WASHER NON-INSULATING
20613-9401 WASHER TO220 ADHESIVE
20661-0225 SPACER Hex M3 x 12ZPST
20661-0408 SPACER Rnd/Hex/ST 2.5 L
20670-0135 CLIP GP02 FOR PCB MTG H/SINKS
20670-0200 HEATSINK PCB MTG 50MM HIGH
20670-0260 HEATSINK DRILLED M/F -0261
22109-0050 TRANSFORMER HF POWER - CPX
22109-0070 TRANSFORMER CURRENT SENSE CPX
22154-0120 CHOKE 10uH AXIAL 35 MILLIOHMS
22154-0110 CHOKE 130uH/4A
22154-0090 CHOKE 10UH/12A - CPX
22154-0200 CHOKE 1mH/10A COMMON MODE CPX
22154-0220 CHOKE 3.3mH/4A COMMON MODE
22300-0211 FUSEHOLDER PCB MOUNTING
22315-0248 FUSE 10A ANTISURGE (T) HBC CER
22315-0402 FUSE 100mAT TL PCB MTG
22520-0160 AC MAINS RECEP 10AMP R/ANG MTG
22573-0202 HEADER 2 WAY STRAIGHT .156P
22573-0204 HEADER 4 WAY STRAIGHT .156P
22573-0205 HEADER 5 WAY STRAIGHT .156P
22573-0206 HEADER 6 WAY STRAIGHT .156P
22573-0207 HEADER 7 WAY STRAIGHT .156P
22575-0062 HEADER 10 WAY (2X5) STR
23183-3470 RES 47KJ 1W CF
23183-4100 RES 100KJ 1W CF
23184-0047 RES 4R7J 2W CF
23184-2120 RES 1K2J 2W CF
23190-1100 RES 100RJ 2W5 500PPM TYPE PR52
23202-0270 RES 27R0F W25 MF 50PPM
23202-1220 RES 220RF W25 MF 50PPM
23202-1330 RES 330RF W25 MF 50PPM
23202-2100 RES 1K00F W25 MF 50PPM
23206-0470 RES 47R0F W60 MF 50PPM
23206-5680 RES 6M80F W6 MF 50PPM
PCB ASSY - MAIN (44115-0800) continued/...
18
Description
FOR D3,4,103,104
FOR Q1,2,101,102
FOR D3,4,103,104
FOR PCB
MAIN/CONTROL PCBS
FOR Q1,2,101,102
SK2,3,102,103
SK1,101
T1,101
T2,102
L1,2
L3
L5,105
L7,107
L4
FOR FS1
FS1
FS2,102
PJ3
PJ2,102
PJ9
PJ5,105
PJ10
PJ1A,6
PJ4,104
R21,121
R1,2
R16,116
R13,17,20,113,117,120
R8,9,10,108,109,110
R4,6,104,106
R11,12,111,112
R18,118
R5,7,105,107
R15,115
R19,119
