TTI CPX200 Service Manual page 18

Part No. Position
23685-0002 CAP 1N0J 100V P/P
23685-0007 CAP 100NK 160V P/P P10
25021-0901 DIO 1N4148 B/R
25115-0907 DIO 1N4002 B/R
25130-0903 DIO ZEN 5V1 W4
25211-9302 RECTIFIER BRIDGE W02G
25336-5590 TRAN PNP BC559C
25380-0229 TRAN NPN BC549
25601-0470 TRAN MOSFET N CHAN 2N7000
27001-0020 OPTO-COUPLER CNY17-3
27001-0030 OPTO-COUPLER HCPL-4503
27103-0020 IC LM339
27106-0520 IC OP-07
27153-0030 IC 7109
27160-0014 IC V/REG 7905
27160-0017 IC V/REG 7812
27160-0440 IC V/REG LM2940CT5
27161-0120 IC V/REF ZN404/ZRA245 2.45V
27168-0020 IC UC3846N
27226-0510 IC 4051B
27250-2000 IC MCU8 PIC16C55XT-P
28502-0010 RESONATOR CER 4MHZ CSA4.00MG
35555-2250 PCB - CONTROL
PCB ASSY - MAIN (44115-0800)
Part Number Description
20030-0263 WASHER M3 ZPST
20037-0301 WASHER M3 SHK/PROOF I/T ZPST
20038-9501 WASHER M3 Spring
20062-9303 SCREW NO 6x0.5in. PNHDPZ ST/AB
20062-9305 SCREW No.6x3/4in. Pozi. Pan
20205-0610 STUD M3 X 10 KFH-M3-10ET
20210-0101 NUT M3 ZPST
20234-0025 SCREW M3 X 12 PNHDPZ ZPST
20234-0027 SCREW M3 X 6 PNHDPZ ZPST
Description
C4,104
C45,145
D1,2,3,5,6,8,9,11-17,24,101,102,103,105,
106,108,109, 111-117,124
D7,10,107,110
D4,104
BR1,101
Q3,103
Q2,4,5,102,104,105
Q1,101
OPT2,102
OPT3,4,103,104
IC4,104
IC1,2,6,17,101,102,106,117
IC12,112
IC10,110
IC8,108
IC9,109
D23,123
IC5,105
IC13,14,113,114
IC11,111
XL1,101
Position
FOR D3,4,103,104, PCB, IEC
E,E1,E2
FOR D3,4,103,104, PCB, IEC
FOR SK1,101
MAIN/CONTROL PCB PILLARS
W3,4,103,104, IEC INLET
FOR D3,4,103,104, IEC INLET
FOR D3,4,103,104
FOR PCB SPACERS
