SBC86822 Series All-In-One Mini ITX Board User's Manual
USB Interface
Eight USB ports with fuse protection and complies with
USB Spec. Rev. 2.0
Watchdog Timer
1~255 seconds; up to 255 levels
Graphics
®
Intel 910GMLE GMCH Gen 3.5 integrated graphic engine
Signal/dual channel 18-bit LVDS LCD support
Maximum up to 224MB frame buffer sharing system
memory
Maximum display resolution
LCD backlight control supported
Expansion Slot
PCI slot for 2 Bus master 32-bit expansion
Ethernet
Two RTL8111B Gigabit Ethernet
Wake On LAN (via ATX power supply)
Equipped with RJ-45 interface
Audio
Realtek AC'97 codec audio
MIC-in, Line-out
Power Management
ACPI (Advanced Configuration and Power Interface)
Form Factor
Mini ITX form factor
NOTE All specifications and images are subject to change
without notice.
Introduction
CRT -- 2048 x1536
LVDS -- 1920 X1200 (18-bit single/dual
channel LVDS interface)
3
