DV-7000 Features

The DV-7000 (Figure 1-1) is designed with the following key features:
•
Footed cartridge with a fixed mechanical stand-off nozzle for extremely consistent dots and
increased throughput
•
Luer-cartridge option allows use with a wide range of standard needles
•
Tool-free disassembly of wetted parts for quick and easy cleaning
•
Fast cartridge changeover
•
Cartridges are interchangeable with DV-8000 pumps
•
Closed-loop motor control with encoder feedback ensures high repeatability and precision
dispense control
Fluid Syringe
Flexible Fluid
Path (rigid path
2
optional)
Needle
Figure 1-1 DV-7000 (DV-7222-SF1 shown)
Motor
