Asymtek Heli-Flow DV-8000 Series Owner's Manual page 24

Heli-flow pump
Hide thumbs
Table of Contents

Advertisement

Cartridge Body
Seal Guide Tool (P/N
196630)
Seal
(spring side up)
Seal Insertion Tool (P/N
196629)
Figure 4-1 Installing a Cartridge Seal
20
Cartridge Fitting
(Luer)
Figure 4-2 Dispensing Cartridge Exploded
Thrust Collar
Feedscrew
Lower
Bearing
Cartridge
Body
Needle
(Luer)
Needle
Retainer
Operation
