Introduction

Overview

The DV-7000 Series and DV-8000 Series Heli-Flow Pumps are rotary, positive displacement auger valves.
Each valve has a closed-loop, servo-controlled motor with encoder feedback that can reverse to create a
clean fluid cutoff. The DV-7000/DV-8000 pumps are designed and exclusively manufactured by Asymtek to
meet high-volume production requirements.
NOTE
The terms pump and valve are synonymous in this manual.
DV-7000
The DV-7000 (Figure 1-1) can be used as a floating head pump for dispensing dots, or as a standard pump
for dispensing lines and/or patterns. The DV-7000 is available in a luer- or footed-needle design with
interchangeable cartridges, allowing the pump to work with several different fluid types. The DV-7000 has a
hardened auger for use with filled epoxy materials and features a high flow rate.

Dispensing Systems

•
X-1010 Axiom™ SMT Dispensing System
•
M-2010 Millennium
•
C-718 Century
•
D-550 DispenseMate
•
S-820 Spectrum

DV-7000 Configurations

Table 1-1 identifies all currently available standard configurations for the DV-7000 Series pump. Contact
Asymtek or your local distributor for other configurations that may better suit your application.
Model
DV-7222-SF1 Footed needle cartridge
DV-7222-SL1 Luer-lock needle cartridge
DV-7223-CP-SLP Luer-lock needle cartridge
DV-7223-CP-0LP Luer-lock needle cartridge
DV-7321-CL8 Luer-lock needle cartridge
DV-7322-CL8 Luer-lock needle cartridge
DV-7331-CL8 Luer-lock needle cartridge

DV-7000 Specifications

Dimensions Length: 190-192 mm (7.48 - 7.56 inch)
Width:
Depth:
Air Pressure 34-552 kPA (5-80 psi, 0.7 - 5.5 bar)
Depending on the fluid, higher viscosities require higher pressures
Motor Closed-loop control with encoder feedback on the dispensing platform
Introduction
®
Ultra High Speed SMT Dispensing System
®
Precision SMT Dispensing System
®
Series Dispensing System
®
Precision Batch Dispensing System
Table 1-1 DV-7000 Standard Configurations
Description
Table 1-2 DV-7000 Specifications
33 mm (1.3 inch)
72.6 mm (2.86 inch)
Applications
Surface Mount Adhesive, Solder Paste, Silver Epoxy
Surface Mount Adhesive, Solder Paste, Silver Epoxy
Silver Epoxy, Types 3 and 4 Solder Pastes
Types 5 and 6 Solder Pastes
Dam Writing
Glob Top, Encapsulation
Lid Seal
