Asymtek Heli-Flow DV-8000 Series Owner's Manual page 48

1
2
3
4
5
12
13
Item
1 194571
2 194577
3 195360
4 194578
5 194572
6 07-0017-00
7 02-0092-00
8 03-0641-00
9 40-0670
10 03-0685-00
11 03-0873-00
12 03-0630-00
13 42-0997
14 03-0682-00
15 03-0684-00
16 49-2206
17 49-2310
18 49-2206
44
7
6
14
15
16
Part No.
Cap, Valve Body
Pad, Thrust Spring (X2)
Spring, Wave, 3/8 OD, 1/4 ID
Guide, Spring
Coupling, Drive, Hex
QR Spring
Retainer, QR Bearing
Plate, Slide Adapter
Guide, LM Bearing, 25.8
Back Plane
Insert, Backplane
Body, Valve
Cap, Round, Vinyl, 0.109 ID, Blue
Lever, QR
Bearing, QR Lever (X2)
Screw, M2 X 0.4 X 6 FLTHD, PH, REC
SCHS, M2 X 0.4 X 10 mm
Screw, M2 X 0.4 X 6 FLTHD, PH, REC
Figure 8-1 DV-7000 Exploded View (1 of 3)
8
9
17
Description
10
11
18
Parts Replacement
