Parts List/Exploded Views

DV-7000
Tables A-1 through A-3 list spare parts and supplies kits for the DV-7000. Figures A-1 to A-3 show the DV-
7000 in exploded view. These illustrations can be helpful when ordering replacement parts for the pump.
NOTE
Not all parts shown on the exploded views are available separately. Contact Asymtek
Customer Service or your local distributor for availability.
Part Number
03-0684-00
07-0017-00
40-0670
40-2667
194577
194578
195360
Part Number
40-0042
41-0002
41-0112
48-0036
197004
Part
Number
NK-7000 Needle Kit
NK-01 Needle Kit
Valve Kit
(includes Consumables Kit
VK-7000
and Cleaning Kit)
SK-7000 Consumables Kit
VK-7000K Cleaning Kit
SK-7001 Seal Kit
Parts Replacement
Table 8-1 Recommended Spare Parts (DV-7000)
Quick Release Lever Bearing
Quick Release Lever Spring
LM 25.8 Linear Bearing Guide
7/32 X 0.158 Mini Joint Coupling
Spring Thrust Pad
Spring Guide
1/4 ID, 3/8 OD Wave Spring
Table 8-2 Assembly and Adjustment Tools (DV-7000)
Nutdriver, 1/4-inch
Wrench, Hex, 4mm, T-Handle
Wrench, Open End,1/4 X 5/16
Wrench, Allen, Hex, 2.5 mm
DV-7000 Seal Insertion Tools
Table 8-3 List of Kits (DV-7000)
Name
Title
Title
Application
DV-7124-CF1, DV-7222-CF1
DV-7222-CL1
DV-7124-CF1, DV-7222-CF1, DV-7222-CL1
DV-7124-CF1, DV-7222-CF1, DV-7222-CL1
DV-7124-CF1, DV-7222-CF1, DV-7222-CL1
DV-7124-CF1, DV-7222-CF1, DV-7222-CL1
43
