IES-0883
6 GE + 2 SFP Managed Switch -20 to 60C, DIN-rail

User Manual

v1.00 - 1206

Advertisement

Table of Contents
loading

Related Manuals for LevelOne IES-0883

Summary of Contents for LevelOne IES-0883

  • Page 1: User Manual

    IES-0883 6 GE + 2 SFP Managed Switch -20 to 60C, DIN-rail User Manual v1.00 - 1206...

  • Page 2: Preface

    To get the most out of this manual, you should have an understanding of Ethernet networking concepts. In this manual, you will find: Features on the Industrial Managed Gigabit Ethernet Switch · Illustrative LED functions · Installation instructions · Management Configuration · SNMP, IGMP… · Specifications IES-0883 User Manual Page 1...

  • Page 3: Table Of Contents

    STP / R ................................. 45 VLAN ................................51 S ................................... 55 SNMP ................................57 802.1 ................................61 ............................... 64 THER ROTOCOLS COMMAND LINE CONSOLE MANAGEMENT ....................68 ............................ 68 DMINISTRATION ONSOLE ................................77 YSTEM .................................. 86 IES-0883 User Manual Page 2...

  • Page 4: Ies-0883 User Manual Page

    ................................95 RUNKING STP / R ................................. 96 VLAN ................................109 S ................................. 115 SNMP ................................118 802.1 ................................127 ............................. 132 THER ROTOCOLS SPECIFICATIONS ............................143 APPENDIX A ..............................144 APPENDIX B ..............................145 IES-0883 User Manual Page 3...

  • Page 5: Quick Start Guide

    2. The relay contact closes if Power3 is failed but Power1 and Power2 are both on · There are three power inputs can be used. Redundant power function is supported PW3 is DC Jack type with 12VDC input IES-0883 User Manual Page 4...

  • Page 6: Led Status

    Transmitting or Receiving data Amber Connection at 1000Mbps speed Green Connection at 100Mbps speed Connection at 10Mbps speed Alarm Steady State the power redundancy failure has being addressed Alarm State the power redundancy failure has not being addressed IES-0883 User Manual Page 5...

  • Page 7: Functional Description

    Logon to Exec Mode (View Mode): At the “switch_a login:” prompt just type in “root” and press <Enter> to logon to Exec Mode (or View Mode). And the “switch_a>” prompt will show on the screen. IES-0883 User Manual Page 6...
  • Page 8 “M”= 8: 255.0.0.0, 16:255.255.0.0, or 24: 255.255.255.0. For example, At the “switch_a(config-if)#” prompt just type in “ip address 192.168.1.10/24” and press <Enter> to set new IP address (192.168.1.10) and new IP subnet mask (255.255.255.0) for Switch. IES-0883 User Manual Page 7...

  • Page 9: Web Configuration

    Specify the default IP address (192.168.1.10) of the switch in the web browser. A login window will be shown as below: l Enter the factory default login ID: root. Enter the factory default password (no password). Then click on the “Login” button to log on to the switch. IES-0883 User Manual Page 8...

  • Page 10: Product Overview

    When you unpack the product package, you shall find the items listed below. Please inspect the contents, and report any apparent damage or missing items immediately to your authorized reseller. IES-0883 · · Quick Installation Guide · CD Users Manual · RS232 cable IES-0883 User Manual Page 9...

  • Page 11: Product Highlights

    Management Support VLAN Port-based VLAN IEEE802.1Q tagged VLAN TRUNKING MAC-based Trunking with automatic link fail-over PORT-SECURITY Per-port programmable MAC address locking Up to 24 Static Secure MAC addresses per port IEEE802.1x Port-based Network Access Control IES-0883 User Manual Page 10...
  • Page 12 Console port access via RS-232 cable (CLI, Command Line Interface) Telnet remote access SNMP agent: MIB-2 (RFC1213) Bridge MIB (RFC1493) RMON MIB (RFC2819) – statistics, history, alarm and events VLAN MIB (IEEE802.1Q/RFC2674) Private MIB Web browser TFTP software-upgrade capability IES-0883 User Manual Page 11...

  • Page 13: Front Panel Display

    4. The relay contact closes if Power3 is failed but Power1 and Power2 are both on · There are three power inputs can be used. Redundant power function is supported PW3 is DC Jack type with 12VDC input IES-0883 User Manual Page 12...
  • Page 14 Transmitting or Receiving data Amber Connection at 1000Mbps speed Green Connection at 100Mbps speed Connection at 10Mbps speed Alarm Steady State the power redundancy failure has being addressed Alarm State the power redundancy failure has not being addressed IES-0883 User Manual Page 13...

  • Page 15: Physical Ports

    · RJ-45 connectors on TX ports · SC connector on 1000Base-SX/LX/BX fiber port MODE SELECTION · 10Base-T full-duplex mode · 10Base-T half-duplex mode · 100Base-TX full-duplex mode · 100Base-TX half-duplex mode · 1000Base-T/SX/LX/BX full-duplex mode · Auto-negotiating mode IES-0883 User Manual Page 14...

  • Page 16: Switch Management

    Administration console via RS-232 serial port (CLI) The switch provides an onboard serial port, which allows the switch to be configured via a directly connected terminal. External SNMP-based network management application The switch can also be configured via SNMP. IES-0883 User Manual Page 15...

  • Page 17: Installation

    -Make sure that the switch receives adequate ventilation. Do not block the ventilation holes on each side of the switch. Wiring Diagram Field Wiring Terminal Markings: Use Copper Conductors Only, 60/75℃, wire range 12-24 AWG, torque value 7 lb-in. IES-0883 User Manual Page 16...

  • Page 18: Din Rail Mounting

    Push the front of the Industrial Managed Ethernet Extender toward the mounting surface until it audibly snaps into place. Removal: Pull out the lower edge and then remove the Industrial Managed Ethernet Extender from the DIN rail. IES-0883 User Manual Page 17...

  • Page 19: Connecting To Power

    Step 1: Connect the DC power cord to the plug-able terminal block on the switch, and then plug it into a standard DC outlet. Step 2: Disconnect the power cord if you want to shut down the switch. Top View IES-0883 User Manual Page 18...

  • Page 20: Alarms For Power Failure

    6. The relay contact closes if Power3 is failed but Power1 and Power2 are both on Special note: The relay output is normal open position when there is no power to the switch. Please do not connect any power source to this terminal to prevent shorting your power supply. IES-0883 User Manual Page 19...

  • Page 21: Connecting To Your Network

    Step 4: Connect one end of the cable to the switch and the other end to a desired device. Step 5: Once the connections between two end devices are made successfully, turn on the power and the switch is operational. IES-0883 User Manual Page 20...

  • Page 22: Switch Management

    The switch gives you the flexibility to access and manage the switch using any or all of the following methods. The web browser interface and administration console (CLI) support are embedded in the switch software and are available for immediate use. IES-0883 User Manual Page 21...

  • Page 23: Administration Console (Cli)

    The switch echoes characters that it receives as input on the modem port to the current administration console session. The console appears to be directly connected to the external modem. IES-0883 User Manual Page 22...

  • Page 24: Web Management

    SNMP supports transaction-based queries that allow the protocol to format messages and to transmit information between reporting devices and data-collection programs. SNMP runs on top of the User Datagram Protocol (UDP), offering a connectionless-mode service. IES-0883 User Manual Page 23...

  • Page 25: Management Architecture

    The management architecture of the switch adheres to the IEEE open standard. This compliance assures customers that the switch is compatible with, and will interoperate with other solutions that adhere to the same open standard. IES-0883 User Manual Page 24...

  • Page 26: Snmp & Rmon Management

    - Generating an SNMP TRAP frame message to the Network Management Station if the threshold of a c ertain MIB counter is r eached or if other trap conditions (such as the following) are met: IES-0883 User Manual Page 25...

  • Page 27: Rmon Mib (Rfc 2819) And Bridge Mib (Rfc 1493)

    - RMON Event Group – allows a network administrator to define actions based on alarms. SNMP Traps are generated when RMON Alarms are triggered. The action taken in the Network Management Station depends on the specific network management application. IES-0883 User Manual Page 26...

  • Page 28: Bridge Groups Supported

    This group is ap plicable to transparent operation only and SRT bridges. - The dot1dStatic Group – contains objects that describe the entity’s destination-address filtering status. This group is ap plicable to any type of bridge which performs destination-address filtering. IES-0883 User Manual Page 27...

  • Page 29: Web-Based Browser Management

    Enter the factory default password (no password). Or enter a user-defined password if you followed the instructions later and changed the factory default password. Then click on the “Login” button to log on to the switch. IES-0883 User Manual Page 28...

  • Page 30: Understanding The Browser Interface

    Bridging, Static MAC Entry, Port Mirroring TRUNKING Port Trunking STP / RING Global Configuration, RSTP Port Setting, MSTP Properties, MSTP Instance Setting, MSTP Port Setting, Ring Setting VLAN VLAN Mode Setting, 802.1Q VLAN Setting, 802.1Q Port Setting, Port Based VLAN IES-0883 User Manual Page 29...

  • Page 31: Other Protocols

    Global Configuration, 802.1p Priority, DSCP SNMP SNMP General Setting, SNMP v1/v2c, SNMP v3 802.1X Radius Configuration, Port Authentication OTHER PROTOCOLS GVRP, IGMP Snooping, NTP IES-0883 User Manual Page 30...

  • Page 32: System

    3. Password: Click in “Password” text box. Type a password. 4. Retype Password: Click in “Retype Password” text box. Type the same password in “Password” text box again to verify it. 5. Updating setting: Click “Updating setting” button to update your settings. IES-0883 User Manual Page 31...
  • Page 33 “DNS Server” drop-down list to disable or enable DNS Server Setting for the switch. Click the text box and type a new address to change the DNS Server. (Need to choose “Enable” from the “DNS Server” drop-down menu.) 8. Submit: Click “Submit” button when you finished DNS Server. IES-0883 User Manual Page 32...

  • Page 34: Save Configuration

    “Auto save” drop-down list to disable or enable Auto save for the switch. 6. Auto save interval (5~65536 sec): Click in “Auto save interval” text box and type a decimal number between 5 and 65536. 7. Submit: Click “Submit” button when you finished Auto save configuration. IES-0883 User Manual Page 33...

  • Page 35: Firmware Upgrade

    Reboot the switch after completing the upgrade process. Please follow the message on the screen during the firmware upgrade process. Do not turn off the power or perform other functions during this period of time. IES-0883 User Manual Page 34...
  • Page 36 Firmware has been upgraded successfully to the switch. Reboot the switch after completing the upgrade process. IES-0883 User Manual Page 35...
  • Page 37 Reboot Reboot: Click “Reboot” button to restart the switch. IES-0883 User Manual Page 36...
  • Page 38 Logout Logout: Click “Logout” button to logout of the switch. IES-0883 User Manual Page 37...

  • Page 39: Port

    3. Flow control: Click “Flow control” drop-down menu to choose “Disable” or “Enable” from the “Flow control” drop-down list to disable or enable Flow control for the port. 4. Submit: Click “Submit” button when you finished configurations. IES-0883 User Manual Page 38...

  • Page 40: Port Status

    Rate Values: 64kbps, 128kbps, 192kbps, … , 1792kbps. 2Mbps, 3Mbps, 4Mbps, … , 100Mbps. 104Mbps, 112Mbps, 120Mbps, … , 1000Mbps. <Note>: M = 1024k. 3. Update setting: Click “Update setting” button when you finished these Rate Control settings. IES-0883 User Manual Page 39...

  • Page 41: Rmon Statistics

    RMON Statistics Click Port 1 ~ Port 8 to view corresponding RMON Statistics. Per port vlan activities Click Port 1 ~ Port 8 to view corresponding vlan activities. IES-0883 User Manual Page 40...

  • Page 42: Switching

    DLF (Destination Lookup Failure). 4. Storm-control enabled type: Choose “Broadcast” and/or “DLF-Multicast” from “Storm-control enabled type” for the port. 5. Update Setting: Click “Update Setting” button when you finished Threshold level and Storm-control enabled type settings. IES-0883 User Manual Page 41...
  • Page 43 3. Delete MAC address: Click “Delete MAC address” drop-down menu and choose a MAC address from the “Delete MAC address” drop-down list to be discarded from the VLAN. 4. Submit: Click “Submit” button when you finished Static-MAC-Entry Discard settings. IES-0883 User Manual Page 42...

  • Page 44: Port Mirroring

    “Mirror To” drop-down list. 3. Mirror Mode: Click “Mirror Mode” drop-down menu to Choose “Tx/Rx”, “Tx”, or “Rx” from “Mirror Mode” drop-down list. 4. Submit: Click “Submit” button when you finished Port Mirroring settings. IES-0883 User Manual Page 43...

  • Page 45: Trunking

    1. Trunk 1 ~ 4: Trunk 1: Click Port 1 ~ Port 8 to assign ports to Trunk 1 ~ 4. (Maximum 4 ports per Trunk.) 2. Submit: Click “Submit” button when you finished Port Trunking settings. IES-0883 User Manual Page 44...

  • Page 46: Stp / Ring

    4 and 30. 6. STP Version: Click “STP Version” drop-down menu to choose “MSTP”, “RSTP”, or “STP compatible” from “STP Version” drop-down list. 7. Update setting: Click “Update setting” button when you finished Global Configuration. IES-0883 User Manual Page 45...
  • Page 47 6. Edge Port: Click “Edge Port” drop-down menu to Choose “Enable”, “Disable”, or “Auto” from “Edge Port” drop-down list to set Enable, Disable, or Auto Edge Port for the port. 7. Update setting: Click “Update setting” button when you finished RSTP Port Setting. IES-0883 User Manual Page 46...

  • Page 48: Mstp Properties

    BPDU prevents the messages from looping indefinetely in the network. When a bridge receives a MST BPDU that has exceeded the allowed max-hops, it discards the BPDU. 5. Update setting: Click “Update setting” button when you finished MSTP Properties setting. IES-0883 User Manual Page 47...
  • Page 49 MST instance to the value specified. The lower the priority of the bridge, the better the chances are the bridge becoming a root bridge or a designated bridge for the LAN. 2. Update setting: Click “Update setting” button when you finished VLAN Instance Configuration. IES-0883 User Manual Page 48...
  • Page 50 3. Admin. Path Cost: Click in “Admin. Path Cost” text box to set the cost of a path associated with an interface. 4. Update setting: Click “Update setting” button when you finished MSTP Port Setting. IES-0883 User Manual Page 49...
  • Page 51 1” drop-down list. 2. Ring port 2: Click “Ring port 2” drop-down menu to choose Ring port 2 from “Ring port 2” drop-down list. 3. Update setting: Click “Update setting” button when you finished Set ring port. IES-0883 User Manual Page 50...

  • Page 52: Vlan

    1. VLAN Mode Setting: Click “VLAN Mode Setting” drop-down menu to choose “Tag-based VLAN” or “Port-based VLAN” from “VLAN Mode Setting” drop-down list. 2. Update Setting: Click “Update Setting” button when you finished VLAN Mode Setting. IES-0883 User Manual Page 51...

  • Page 53: Q Vlan Setting

    2. Tag or Untag: Click “Tag or Untag” drop-down menu to Choose “Tag” or “Untag” from “Tag or Untag” drop-down list for a “Hybrid” port. 3. Submit: Click “Submit” button when you finished VLAN setting. Delete VLAN: 1. VLAN setting: Click “VLAN setting”. The “VLAN Setting” window appears. IES-0883 User Manual Page 52...

  • Page 54: Vlan Port Setting

    Mode for the port. And the port will be Tag or Untag port if you choose “Hybrid” Mode for the port. 3. PVID: Click in the “PVID” textbox and specify a new PVID number for the port. 4. Update Setting: Click “Update Setting” button when you finished VLAN Port Setting. IES-0883 User Manual Page 53...
  • Page 55 2. Select all: Click “select all” button to choose Port 1 ~ Port 8 all to be added to the VLAN. 3. Delete all: Click “delete all” button to choose Port 1 ~ Port 8 all to be deleted from the VLAN. 4. Submit: Click “Submit” button when you finished Port Based VLAN setting. IES-0883 User Manual Page 54...

  • Page 56: Qos

    4. Weighted Round Robin: Click in the “Weight(1~55)” textbox and specify a new number from 1 ~ 55 for Queue 0 ~ 3. 5. Submit: Click “Submit” button when you finished Global Configuration. IES-0883 User Manual Page 55...
  • Page 57 2. Submit: Click “Submit” button when you finished 802.1p priority. DSCP 1. Priority: Click “Priority” drop-down menu from “Priority” drop-down list to choose 0 ~ 3 for DSCP Priority 0 ~ 63. 2. Submit: Click “Submit” button when you finished DSCP. IES-0883 User Manual Page 56...

  • Page 58: Snmp

    “Enable” or “Disable” to enable or disable link up trap. 11. Authentication Failure Trap: Click “Authentication Failure Trap” drop-down menu from “Authentication Failure Trap” drop-down list to choose “Enable” or “Disable” to enable or disable authentication failure trap. IES-0883 User Manual Page 57...
  • Page 59 1. Get Community Name: Click in the “Get Community Name” textbox and specify a get community name. 2. Set Community Name: Click in the “Set Community Name” textbox and specify a set community name. 3. Update Setting: Click “Update Setting” button when you finished SNMP V1/V2c Setting. IES-0883 User Manual Page 58...
  • Page 60 Ÿ Read Only: Add a user using SNMP v3 with read-only access mode. Ÿ Read/Write: Add an user using SNMP v3 with read-write access mode 5. Sumit: Click “Sumit” button when you finished SNMP V3 Setting. IES-0883 User Manual Page 59...
  • Page 61 2. Select User Name: Click “Select User Name” drop-down menu from “Select User Name” drop-down list to choose the user to be deleted from using SNMP v3. 3. Sumit: Click “Sumit” button when you finished user deletion. IES-0883 User Manual Page 60...

  • Page 62: Radius Configuration

    Switch and radius server. This key must match the encryption used on the radius daemon. All leading spaces are ignored, but spaces within and at the end of the key are used. If spaces are used in the IES-0883 User Manual Page 61...
  • Page 63 2. Select Radius Server IP: Click “Select Radius Server IP” drop-down menu from “Select Radius Server IP” drop-down list to choose the IP address of the remote radius server host to be deleted. 3. Sumit: Click “Sumit” button when you finished radius server deletion. IES-0883 User Manual Page 62...
  • Page 64 5. Reauthentication Period <1-4294967295>: Click in the “Reauthentication Period” textbox and specify the seconds between reauthorization attempts. The default time is 3600 seconds. 6. Update Setting: Click “Update Setting” button when you finished port-based authentication setting. IES-0883 User Manual Page 63...

  • Page 65: Other Protocols

    3. GVRP registration: Click “GVRP registration” drop-down menu from “GVRP registration” drop-down list to choose “Enable” or “Disable” to enable or disable GVRP registration to the port. Configuring an IEEE802.1Q trunk port in registration mode allows dynamic IES-0883 User Manual Page 64...
  • Page 66 1 ~ 124. This determines the maximum amount of time in seconds allowed before sending an IGMP response report. The max-response-time field allows an entry between 1 and 124 (seconds). Default = 10. IGMP passive snooping: 1. Report suppression: Click “report suppression” drop-down menu from “report IES-0883 User Manual Page 65...
  • Page 67 6. Update Setting: Click “Update Setting” button when you finished NTP Setting. Daylight Saving Setting: 1. Daylight Saving Mode: Click "Daylight Saving Mode" drop-down menu from "Daylight Saving Mode" drop-down list to choose "Disable", "Weekday", or "Date" to choose IES-0883 User Manual Page 66...
  • Page 68 6. Update Setting: Click "Update Setting" button when you finished Daylight Saving Setting. <Note> The “Week”, “Hour”, “Minute”, and “Day” fields would not accept the alphabetic characters (Like Jan, Feb, sun, mon). They only accept the two digit numbers (0 throught 9). IES-0883 User Manual Page 67...

  • Page 69: Command Line Console Management

    When using the management method, configure the terminal-emulation program to use the following parameters (you can change these settings after login): [Default parameters] 115,200bps 8 data bits No parity 1 stop bit Exec Mode (View Mode) Logon to Exec Mode (View Mode) IES-0883 User Manual Page 68...
  • Page 70 At the switch_a> prompt just type in the full or partial command string then typing a question mark “? ” to display the command keywords or parameters along with a short description. switch_a>show ? IES-0883 User Manual Page 69...
  • Page 71 Logon back to Exec Mode (View Mode) At the switch_a login: prompt just type in “root” and press <Enter> to logon back to Exec Mode (or View Mode). switch_a login: root IES-0883 User Manual Page 70...
  • Page 72 Logon to Privileged Exec Mode (Enable Mode) At the switch_a> prompt just type in “enable” and press <Enter> to logon to Privileged Exec Mode (or Enable Mode). And the switch_a# prompt will show on the screen. switch_a>enable IES-0883 User Manual Page 71...
  • Page 73 Privileged Exec Mode (or Enable Mode) allows users to run commands as following. At the switch_a# prompt just press <?> to list the commands. switch_a#? At the switch_a# prompt just type in the full or partial command string then typing a IES-0883 User Manual Page 72...
  • Page 74 And the switch_a login: prompt will show on the screen. Logon back to Exec Mode (View Mode) At the switch_a login: prompt just type in “root” and press <Enter> to logon back to Exec Mode (or View Mode). switch_a login: root IES-0883 User Manual Page 73...
  • Page 75 Logon to Configure Mode (Configure Terminal Mode) At the switch_a# prompt just type in “configure terminal” and press <Enter> to logon to Configure Mode (or Configure Terminal Mode). And the switch_a(config)# prompt will show on the screen. switch_a#configure terminal IES-0883 User Manual Page 74...
  • Page 76 Commands Configure Mode (or Configure Terminal Mode) serves as a gateway into the modes as following. At the switch_a(config)# prompt just press <?> to list the commands. switch_a(config)#? IES-0883 User Manual Page 75...
  • Page 77 Mode (or View Mode). switch_a login: root Exit from Configure Mode (or Configure Terminal Mode) At the switch_a(config)# prompt just type in “exit” and press <Enter> to exit from Configure Mode (or Configure Terminal Mode). switch_a(config)#exit IES-0883 User Manual Page 76...

  • Page 78: System

    The following example sets the hostname to switch, and shows the change in the prompt: switch_a(config)#hostname switch switch(config)# Password: 1. Command Mode: Configure mode Logon to Configure Mode (Configure Terminal Mode). The switch_a(config)# prompt will show on the screen. IES-0883 User Manual Page 77...
  • Page 79 Use enable password command to modify or create a password to be used when entering the Enable mode. 3. Command Syntax: enable password PASSWORD PASSWORD specifies the new password of the system. 4. Example: The following example sets the new password mypasswd to switch: switch_a(config)#enable password mypasswd switch_a(config)# IES-0883 User Manual Page 78...
  • Page 80 Use the no ip default-gateway command to remove the IP address of the default gateway. 3. Command Syntax: ip default-gateway IP-ADDRESS no ip default-gateway IP-ADDRESS A.B.C.D specifies the IP address of the default gateway. 4. Example: IES-0883 User Manual Page 79...
  • Page 81 IP-ADDRESS specifies the IP address of tftp server. WORD specifies the file name to be loaded to switch. 4. Example: The following example specifies upgrading firmware (file name: flash.tgz) from tftp server (IP address: 192.168.1.100) to switch: switch_a#install image 192.168.1.100 flash.tgz IES-0883 User Manual Page 80...
  • Page 82 3. Command Syntax: copy running-config startup-config 4. Example: The following example specifies writing configurations to the file to be used at startup to switch: switch_a#copy running-config startup-config switch_a# Restore Default: 1. Command Mode: Privileged Exec mode IES-0883 User Manual Page 81...
  • Page 83 Auto Save Interval (5~65536 sec): 1. Command Mode: Configure mode Logon to Configure Mode (Configure Terminal Mode). The switch_a(config)# prompt will show on the screen. switch_a(config)# 2. Usage: IES-0883 User Manual Page 82...
  • Page 84 (IP address: 192.168.1.100) to switch: switch_a#install image 192.168.1.100 flash.tgz switch_a# Please follow the message on the screen during the firmware upgrade process. Do not turn off the power or perform other functions during this period of time. IES-0883 User Manual Page 83...
  • Page 85 Logon to Privileged Exec Mode (Enable Mode). The switch_a# prompt will show on the screen. switch_a# 2. Usage: Use reload command to restart switch. 3. Command Syntax: reload 4. Example: The following example specifies restarting switch: IES-0883 User Manual Page 84...
  • Page 86 Use logout command to exit from the Exec mode or Privileged Exec mode. 3. Command Syntax: logout 4. Example: The following example specifies to exit from the Exec mode or Privileged Exec mode. switch_a>logout switch_a login: IES-0883 User Manual Page 85...

  • Page 87: Port

    The switch_a(config-if)# prompt will show on the screen. switch_a(config)#interface fe1 switch_a(config-if)# 2. Usage: Use duplex command to specify the duplex mode to be used for each interface. Use the no duplex to disable this function. 3. Command Syntax: (no) duplex MODE IES-0883 User Manual Page 86...
  • Page 88 Logon to Exec Mode (View Mode) or Privileged Exec Mode (Enable Mode). The switch_a> or switch_a# prompt will show on the screen. switch_a> switch_a# 2. Usage: Use the show interface command to display interface configuration and status. IES-0883 User Manual Page 87...
  • Page 89 10m switch_a(config-if)# RMON Statistics 1. Command Mode: Exec mode or Privileged Exec mode Logon to Exec Mode (View Mode) or Privileged Exec Mode (Enable Mode). The switch_a> or switch_a# prompt will show on the screen. IES-0883 User Manual Page 88...
  • Page 90 Use show vlan command to display information about a particular VLAN by specifying the VLAN ID. 3. Command Syntax: show vlan <2-4094> <2-4094> VLAN ID. 4. Example: The following is an output of show vlan command displaying information about VLAN 2: switch_a>show vlan 2 IES-0883 User Manual Page 89...

  • Page 91: Switching

    The storm control action occurs when traffic utilization reaches this level. 3. Command Syntax: storm-control level LEVEL LEVEL <0-100> specifies the percentage of the threshold; percentage of the maximum speed (pps) of the interface. IES-0883 User Manual Page 90...
  • Page 92 Logon to Configure Mode (Configure Terminal Mode). Then logon to Interface mode. fe1 means port 1. The switch_a(config-if)# prompt will show on the screen. switch_a(config)#interface fe1 switch_a(config-if)# 2. Usage: Use storm-control multicast enable command to enable multicast traffic. IES-0883 User Manual Page 91...
  • Page 93 The following example shows setting storm-control dlf enable to the interface fe1 (port switch_a(config)#interface fe1 switch_a(config-if)#storm-control dlf enable switch_a(config-if)# Static MAC Entry Static-MAC-Entry Forward: 1. Command Mode: Configure mode Logon to Configure Mode (Configure Terminal Mode). The switch_a(config)# prompt will show on the screen. IES-0883 User Manual Page 92...
  • Page 94 VLANID The VID of the VLAN on the bridge <1-4094>. 4. Example: The following example configures a bridge GROUP (1) to discard matching frames (MAC address 2222.2222.2222) in vlan VLANID (1): switch_a(config)#bridge 1 address 2222.2222.2222 discard vlan 1 switch_a(config)# IES-0883 User Manual Page 93...
  • Page 95 Specifies mirroring of transmitted traffic. 4. Example: The following example enables port mirroring by the destination port fe1 (port 1) on the specified source port fe2 (port 2): switch_a(config)#interface fe1 switch_a(config-if)#mirror interface fe2 direction both switch_a(config-if)# IES-0883 User Manual Page 94...

  • Page 96: Trunking

    <1-3> Channel group number. Maximum 4 ports in static-channel-group 1 and static-channel-group 2. Maximum 2 ports in static-channel-group 3 4. Example: The following example adding the interface fe1 (port 1) to static-channel-group 1: switch_a(config)#interface fe1 switch_a(config-if)#static-channel-group 1 switch_a(config-if)# IES-0883 User Manual Page 95...

  • Page 97: Stp / Ring

    Use the no form of the command to disable the Multiple Spanning Tree protocol on a bridge. 3. Command Syntax: bridge GROUP multiple-spanning-tree enable no bridge GROUP multiple-spanning-tree enable BRIDGE-FORWARD GROUP <1-1> Bridge group name used for bridging. IES-0883 User Manual Page 96...
  • Page 98 Use the no form of the command to disable the Spanning Tree protocol on a bridge. 7. Command Syntax: bridge GROUP spanning-tree enable no bridge GROUP spanning-tree enable BRIDGE-FORWARD GROUP <1-1> Bridge group name used for bridging. IES-0883 User Manual Page 97...
  • Page 99 Use this command to set the hello-time, the time in seconds after which (if this bridge is the root bridge) all the bridges in a bridged LAN exchange Bridge Protocol Data Units (BPDUs). 3. Command Syntax: bridge GROUP hello-time HELLOTIME no bridge GROUP hello-time IES-0883 User Manual Page 98...
  • Page 100 Use this command to set the time (in seconds) after which (if this bridge is the root bridge) each port changes states to learning and forwarding. Use the no parameter with this command to restore the default value. 3. Command Syntax: bridge GROUP forward-time FORWARD_DELAY no bridge GROUP forward-time IES-0883 User Manual Page 99...
  • Page 101 Admin. Path Cost: 1. Command Mode: Interface mode Logon to Configure Mode (Configure Terminal Mode). Then logon to Interface mode. fe1 means port 1. The switch_a(config-if)# prompt will show on the screen. switch_a(config)#interface fe1 switch_a(config-if)# IES-0883 User Manual Page 100...
  • Page 102 LINKTYPE The link type to be assigned to the port. point-to-point Enable rapid transition. shared Disable rapid transition. 4. Example: The following example sets the link-type LINKTYPE (point-to-point) of the interface fe1 (port 1): switch_a(config)#interface fe1 switch_a(config-if)#spanning-tree link-type point-to-point switch_a(config-if)# IES-0883 User Manual Page 101...
  • Page 103 Use the no spanning-tree edgeport command to set a port to its default state (not an edge-port) and to disable rapid transitions. 3. Command Syntax: (no) spanning-tree edgeport 4. Example: The following example enables the spanning-tree edgeport of the interface fe1 (port 1): IES-0883 User Manual Page 102...
  • Page 104 Then logon to MST Configuration mode. The switch_a(config-mst)# prompt will show on the screen. switch_a(config)#spanning-tree mst configuration switch_a(config-mst)# 2. Usage: Use this command to specify the number for configuration information. The default value of revision number is 0. IES-0883 User Manual Page 103...
  • Page 105 1 max-hops 25 switch_a(config)# MSTP Instance Setting Bridge Instance VLAN: 1. Command Mode: MST Configuration mode Logon to Configure Mode (Configure Terminal Mode). Then logon to MST Configuration mode. The switch_a(config-mst)# prompt will show on the screen. IES-0883 User Manual Page 104...
  • Page 106 GROUP <1-1> Specify the bridge-group ID. INSTANCE_ID Specify the instance ID. BRIDGE_PRIORITY <0-61440> Specify the bridge priority. 4. Example: The following example sets the bridge priority (0) for an MST instance (3) in bridge GROUP IES-0883 User Manual Page 105...
  • Page 107 2. Usage: Use this command to set the port priority for a bridge group. The Multiple Spanning Tree Protocol uses port priority as a tiebreaker to determine which port should forward frames IES-0883 User Manual Page 106...
  • Page 108 PATH_COST <1-200000000> Specify the cost of path in the range of <1-200000000>. 4. Example: The following example sets the path cost (1000) for Multiple Spanning Tree instance (3) to a port (fe1) in bridge GROUP (1): switch_a(config)#interface fe1 switch_a(config-if)#bridge-group 1 instance 3 path-cost 1000 switch_a(config-if)# IES-0883 User Manual Page 107...
  • Page 109 RING_PORT_1 Specify the Ring port 1. RING_PORT_2 Specify the Ring port 2. 4. Example: The following example sets the fe1 and fe2 as Ring port 1 and Ring port 2: switch_a(config)#ring set-port fe1 fe2 switch_a(config)# IES-0883 User Manual Page 108...

  • Page 110: Vlan

    VLANID The VID of the VLAN that will be enabled or disabled on the bridge <2-4094>. GROUP <1-1> The ID of the bridge-group on which the VLAN will be affected. VLAN_NAME The ASCII name of the VLAN. Maximum length: 16 characters. enable Sets VLAN into an enable state. IES-0883 User Manual Page 109...
  • Page 111 Switchport mode hybrid: 1. Command Mode: Interface mode Logon to Configure Mode (Configure Terminal Mode). Then logon to Interface mode. fe1 means port 1. The switch_a(config-if)# prompt will show on the screen. switch_a(config)#interface fe1 switch_a(config-if)# IES-0883 User Manual Page 110...
  • Page 112 Use the no switchport trunk command to reset the mode of the Layer-2 interface to access (default). 3. Command Syntax: switchport mode trunk no switchport trunk 4. Example: The following example sets the switchport mode trunk of the interface fe1 (port 1): switch_a(config)#interface fe1 switch_a(config-if)#switchport mode trunk switch_a(config-if)# IES-0883 User Manual Page 111...
  • Page 113 )#switchport hybrid allowed vlan add 2 egress-tagged enable switch_a(config-if )# Switchport trunk allowed vlan: 1. Command Mode: Interface mode Logon to Configure Mode (Configure Terminal Mode). Then logon to Interface mode. fe1 means port 1. IES-0883 User Manual Page 112...
  • Page 114 Switchport portbase add/remove vlan: 1. Command Mode: Interface mode Logon to Configure Mode (Configure Terminal Mode). Then logon to Interface mode. fe1 means port 1. The switch_a(config-if)# prompt will show on the screen. switch_a(config)#interface fe1 switch_a(config-if)# IES-0883 User Manual Page 113...
  • Page 115 VLANID The ID of the VLAN will be added to or removed from the Layer-2 interface. 4. Example: The following example specifies to add the interface fe1 (port 1) to VLANID (2): switch_a(config)#interface fe1 switch_a(config-if)#switchport portbase add vlan 2 switch_a(config-if)# IES-0883 User Manual Page 114...

  • Page 116: Qos

    3. Command Syntax: (no) mls qos trust cos/dscp cos Class of Service. dscp Differentiated Service Code Point. 4. Example: The following example turns on QoS trust CoS on the switch: switch_a(config)#mls qos trust cos switch_a(config)# IES-0883 User Manual Page 115...
  • Page 117 WRR_WTS Weighted Round Robin (WRR) weights for the 4 queues (4 values separated by spaces). Range is 1-55. 4. Example: The following example specifies the bandwidth ratios of the transmit queues on the switch: switch_a(config)#wrr-queue bandwidth 1 2 4 8 switch_a(config)# 802.1p Priority 1. Command Mode: Configure mode IES-0883 User Manual Page 116...
  • Page 118 QUEUE_ID Queue ID. Range is 0-3. 4. Example: The following example shows mapping DSCP values 0 to 3 to queue 1 on the switch: switch_a(config)#mls qos map dscp-queue 0 1 2 3 to 1 switch_a(config)# IES-0883 User Manual Page 117...

  • Page 119: Snmp

    Use snmp-server description command to specify and no snmp-server description command to remove description for SNMP. 3. Command Syntax: snmp-server description DESCRIPTION no snmp-server description DESCRIPTION The description for SNMP. 4. Example: The following example specifies description (description) for SNMP: switch_a(config)#snmp-server description description switch_a(config)# IES-0883 User Manual Page 118...
  • Page 120 3. Command Syntax: snmp-server contact CONTACT no snmp-server contact CONTACT The contact for SNMP. 4. Example: The following example specifies contact (contact) for SNMP: switch_a(config)#snmp-server contact contact switch_a(config)# Trap Community Name: 1. Command Mode: Configure mode IES-0883 User Manual Page 119...
  • Page 121 IP-ADDRESS The trap host IP address for SNMP. A.B.C.D specifies the IP address. 4. Example: The following example specifies trap host 1 IP address (192.168.1.20) for SNMP: switch_a(config)#snmp-server trap-ipaddress 1 192.168.1.20 switch_a(config)# Cold Start Trap: 1. Command Mode: Configure mode Logon to Configure Mode (Configure Terminal Mode). IES-0883 User Manual Page 120...
  • Page 122 The following example enables warm start trap for SNMP: switch_a(config)#snmp-server trap-type enable warmStart switch_a(config)# Link Down Trap: 1. Command Mode: Configure mode Logon to Configure Mode (Configure Terminal Mode). The switch_a(config)# prompt will show on the screen. switch_a(config)# IES-0883 User Manual Page 121...
  • Page 123 Logon to Configure Mode (Configure Terminal Mode). The switch_a(config)# prompt will show on the screen. switch_a(config)# 2. Usage: Use snmp-server trap-type enable authenticationFailure command to enable authentication failure trap for SNMP. Use the no snmp-server trap-type enable authenticationFailure command to disable IES-0883 User Manual Page 122...
  • Page 124 The switch_a(config)# prompt will show on the screen. switch_a(config)# 2. Usage: Use snmp-server community get command to specify and no snmp-server community get command to remove get community name for SNMP. 3. Command Syntax: snmp-server community get NAME IES-0883 User Manual Page 123...
  • Page 125 Add a user using snmp v3 with read-only or read-write access mode and without authentication. Use the no form of the command to delete this user. 3. Command Syntax: (no) snmp-server v3-user USERNAME (ro｜rw) noauth USERNAME Specify a user name. ro read-only access mode IES-0883 User Manual Page 124...
  • Page 126 The switch_a(config)# prompt will show on the screen. switch_a(config)# 2. Usage: Add a user using snmp v3 with read-only or read-write access mode, MD5 or SHA authentication, and privacy. Use the no form of the command to delete this user. IES-0883 User Manual Page 125...
  • Page 127 PRIV_PASS_PHRASE encryption pass phrase 4. Example: The following example adds a user (myuser) using snmp v3 with read-write access mode, MD5 authentication (mypassword), and encryption pass phrase (mypassphrase): switch_a(config)#snmp-server v3-user myuser rw priv md5 mypassword des mypassphrase switch_a(config)# IES-0883 User Manual Page 126...
  • Page 128 0. 4. Example: The following example specifies the IP address (192.168.1.100) of the remote radius server host and assigns authentication and accounting destination port number (1812): switch_a(config)#radius-server host 192.168.1.100 auth-port 1812 IES-0883 User Manual Page 127...
  • Page 129 Enter a value in the range 1 to 1000. 4. Example: The following example specifies 20 seconds for the Switch to wait for a server host to reply before timing out: switch_a(config)#radius-server timeout 20 IES-0883 User Manual Page 128...

  • Page 130: Port Authentication

    Use no dot1x reauthetication command to disable reauthentication on a port. 3. Command Syntax: (no) dot1x reauthentication 4. Example: The following example specifies to enable reauthetication on the interface fe1 (port 1): switch_a(config)#interface fe1 switch_a(config-if)#dot1x reauthentication IES-0883 User Manual Page 129...
  • Page 131 The switch_a(config-if)# prompt will show on the screen. switch_a(config)#interface fe1 switch_a(config-if)# 2. Usage: Use this command to set the interval between reauthorization attempts. Use no dot1x timeout re-authperiod command to delete the interval between reauthorization attempts. IES-0883 User Manual Page 130...
  • Page 132 SECS <1-4294967295> Specify the seconds between reauthorization attempts. The default time is 3600 seconds. 4. Example: The following example specifies to set the interval 25 seconds between reauthorization attempts: switch_a(config)#interface fe1 switch_a(config-if)#dot1x timeout re-authperiod 25 switch_a(config-if)# IES-0883 User Manual Page 131...

  • Page 133: Other Protocols

    VLAN creation for a specific bridge instance. 3. Command Syntax: set gvrp dynamic-vlan-creation enable bridge GROUP set gvrp dynamic-vlan-creation disable bridge GROUP GROUP Bridge-group ID used for bridging. 4. Example: IES-0883 User Manual Page 132...
  • Page 134 Use this command to set the GVRP applicant state to normal or active. 3. Command Syntax: set gvrp applicant state active/normal IFNAME active Active state normal Normal state IFNAME Name of the interface. 4. Example: IES-0883 User Manual Page 133...
  • Page 135 1. Command Mode: Configure mode Logon to Configure Mode (Configure Terminal Mode). The switch_a(config)# prompt will show on the screen. switch_a(config)# 2. Usage: Use ip igmp snooping querier command to enable IGMP querier operation on a subnet IES-0883 User Manual Page 134...
  • Page 136 IGMP version: 1. Command Mode: Interface mode Logon to Configure Mode (Configure Terminal Mode). Then logon to Interface mode. vlan1.1 means vlan 1. The switch_a(config-if)# prompt will show on the screen. switch_a(config)#interface vlan1.1 switch_a(config-if)# 2. Usage: IES-0883 User Manual Page 135...
  • Page 137 (no) ip igmp snooping fast-leave 4. Example: The following example enables IGMP snooping fast-leave on vlan1.1: switch_a(config)#interface vlan1.1 switch_a(config-if)#ip igmp snooping fast-leave switch_a(config-if)# IGMP querier: Query-interval: 1. Command Mode: Interface mode Logon to Configure Mode (Configure Terminal Mode). IES-0883 User Manual Page 136...
  • Page 138 To restore to the default value, use the no ip igmp query-max-response-time command. 3. Command Syntax: ip igmp query-max-response-time RESPONSETIME no ip igmp query-max-response-time RESPONSETIME <1-240> Maximum response time (in seconds) advertised in IGMP queries. Default: 10 seconds. IES-0883 User Manual Page 137...
  • Page 139 IGMP passive snooping: Report suppression: 1. Command Mode: Interface mode Logon to Configure Mode (Configure Terminal Mode). Then logon to Interface mode. vlan1.1 means vlan 1. The switch_a(config-if)# prompt will show on the screen. switch_a(config)#interface vlan1.1 switch_a(config-if)# IES-0883 User Manual Page 138...
  • Page 140 The following example enables NTP for the Switch: switch_a(config)#ntp enable switch_a(config)# NTP Server: 1. Command Mode: Configure mode Logon to Configure Mode (Configure Terminal Mode). The switch_a(config)# prompt will show on the screen. switch_a(config)# 2. Usage: IES-0883 User Manual Page 139...
  • Page 141 The switch_a(config)# prompt will show on the screen. switch_a(config)# 2. Usage: Use this command to to set time zone. 3. Command Syntax: clock timezone TIMEZONE TIMEZONE Specifies the time zone. (Please refer the Appendix B) 4. Example: IES-0883 User Manual Page 140...
  • Page 142 HOUR <0-23> Specifies from 0 to 23. MINUTE <0-59> Specifies from 0 to 59. OFFSET <1-1440> Specifies from 1 to 1440 minutes. clock summer-time TIMEZONE date DAY MONTH HOUR MINUTE DAY MONTH HOUR MINUTE OFFSET IES-0883 User Manual Page 141...
  • Page 143 The following example sets clock summer-time TIMEZONE (onehour) as daylight saving offset 60 minutes from 4 April AM0:00 to 31 October AM0:00: switch_a(config)#clock summer-time onehour date 4 4 0 0 31 10 0 0 60 switch_a(config)# IES-0883 User Manual Page 142...

  • Page 144: Specifications

    EN61000-4-2 (ESD Standard) EN61000-4-3 (Radiated RFI Standards) EN61000-4-4 (Burst Standards) EN61000-4-5 (Surge Standards) EN61000-4-6 (Induced RFI Standards) EN61000-4-8 (Magnetic Field Standards) Environmental Test IEC60068-2-6 Fc (Vibration Resistance) Compliance IEC60068-2-27 Ea (Shock) IEC60068-2-32 Ed (Free Fall) IES-0883 User Manual Page 143...

  • Page 145: Appendix A

    Appendix A DB9 DCE pin assignment Name RS232 Signal name Data Carrier detect Received data Transmit data Signal ground Data set Ready Clear to send IES-0883 User Manual Page 144...

  • Page 146: Appendix B

    Asia/Almaty, Asia/Qyzylorda EUT-8EUTDST Asia/Ulaanbaatar Russian Federation RFT-2RFTDST Europe/Kaliningrad RFT-3RFTDST Europe/Moscow RFT-4RFTDST Asia/Yerevan, Asia/Baku, Asia/Oral, Asia/Ashkhabad RFT-5RFTDST Asia/Aqtobe, Asia/Aqtau, Asia/Bishkek, Asia/Yekaterinburg RFT-6RFTDST Asia/Omsk, Asia/Novosibirsk RFT-7RFTDST Asia/Hovd, Asia/Krasnoyarsk RFT-8RFTDST Asia/Irkutsk, Asia/Chungking, Asia/Ulan_Bator RFT-9RFTDST Asia/Choibalsan, Asia/Yakutsk RFT-10RFTDST Asia/Vladivostok IES-0883 User Manual Page 145...
  • Page 147 Pacific/Pitcairn, America/Juneau, America/Yakutat, America/Anchorage, America/Nome, US/Alaska, SystemV/YST9YDT, SystemV/PST8 South America & Central America TTST4 America/Port_of_Spain SAT3 America/Argentina/Buenos_Aires, America/Argentina/Cordoba, America/Argentina/Tucuman, America/Argentina/La_Rioja, America/Argentina/San_Juan, America/Argentina/Jujuy, America/Argentina/Catamarca, America/Argentina/Mendoza, America/Argentina/Rio_Gallegos, America/Argentina/Ushuaia, America/Argentina/ComodRivadavia, America/Buenos_Aires, America/Cordoba, America/Jujuy, America/Mendoza EBST3EBDT America/Fortaleza, America/Recife, America/Araguaina, America/Maceio, IES-0883 User Manual Page 146...
  • Page 148 EST-2EDT Africa/Cairo, Egypt UAEST-4 Asia/Dubai IST-3IDT Asia/Baghdad JST-2JDT Asia/Amman SST-2SDT Asia/Damascus Universal Africa/Ouagadougou, Africa/Abidjan, Africa/Banjul, Africa/Accra, Africa/Conakry, Africa/Bissau, Africa/Monrovia, Africa/Bamako, Africa/Nouakchott, Africa/Casablanca, Africa/El_Aaiun, Atlantic/St_Helena, Africa/Sao_Tome, Africa/Dakar, Africa/Freetown, Africa/Lome, America/Danmarkshavn, Atlantic/Reykjavik, Etc/GMT, Etc/UTC, Etc/UCT, GMT, Etc/Universal, IES-0883 User Manual Page 147...
  • Page 149 Africa/Kinshasa, Africa/Brazzaville, Africa/Malabo, Africa/Libreville, Africa/Windhoek, Africa/Niamey, Africa/Lagos, Etc/GMT-1 UCT-2 Africa/Gaborone, Africa/Bujumbura, Africa/Lubumbashi, Africa/Tripoli, Africa/Blantyre, Africa/Maputo, Africa/Kigali, Africa/Lusaka, Africa/Harare, Etc/GMT-2, Libya UCT-3 Indian/Comoro, Africa/Djibouti, Africa/Asmera, Africa/Addis_Ababa, Africa/Nairobi, Indian/Antananarivo, Indian/Mayotte, Africa/Mogadishu, Africa/Khartoum, Africa/Dar_es_Salaam, Africa/Kampala, Antarctica/Syowa, Asia/Bahrain, Asia/Kuwait, IES-0883 User Manual Page 148...
  • Page 150 Asia/Tehran, Iran UCT-4:30 Asia/Kabul IST-2IDT Asia/Jerusalem, Asia/Gaza, Asia/Tel_Aviv, Israel CST6MEX America/Cancun, America/Merida, America/Monterrey, America/Mexico_City, America/Lima, Mexico/General CST6 America/Regina, America/Swift_Current, Canada/East-Saskatchewan, Canada/Saskatchewan, SystemV/CST6 EET-2EETDST2 Europe/Bucharest EET-2EETDST3 Europe/Tallinn, Europe/Helsinki, Europe/Riga, Europe/Mariehamn EET-2EETDST2W2K Europe/Istanbul UCT-14 Pacific/Kiritimati, Etc/GMT-14 UCT9:30 Pacific/Marquesas IES-0883 User Manual Page 149...
  • Page 151 PST8PDT_MX America/Tijuana, America/Ensenada, Mexico/BajaNorte MST7MDT_MX America/Chihuahua, America/Hermosillo, America/Mazatlan, Mexico/BajaSur CST6CDT_MX America/Guatemala North America (Turks and Caicos) EST5EDT_TC America/Grand_Turk Additions Since 10g RTM EST5EDT_INDIANA America/Indiana/Indianapolis, America/Indiana/Marengo, America/Indiana/Vevay, America/Fort_Wayne, America/Indianapolis, America/Indiana/Knox, America/Knox_IN, US/Indiana-Starke, US/East-Indiana UCT-8_WA Australia/Perth, Australia/West IES-0883 User Manual Page 150...
  • Page 152 IES-0883 User Manual Page 151...
