Page 1: User Manual
IES-0853 4 x 802.3at PoE + 3 FE + 1 MM SC Web Smart Switch -40 to 75C, DIN-rail User Manual v1.00 - 1206... - Page 2 To get the most out of this manual, you should have an understanding of Ethernet networking concepts. In this manual, you will find: Features on the Hardened Web-Smart PoE Ethernet Switch Illustrative LED functions Installation instructions Management Configuration Specifications IES-0853 User Manual Page 2...
-
Page 3: Table Of Contents
NTERFACE PoE ................................14 High Power PoE Operation ......................... 15 Port Based VLAN ............................ 16 Priority ..............................17 Diff Serv Code Point ..........................18 System Setup ............................19 Firmware Upgrade ..........................20 SPECIFICATIONS ....................... 21 IES-0853 User Manual Page 3... -
Page 4: Overview
Overview Hardened Web-Smart PoE Ethernet Switch LevelOne IES-0853 Industry Ethernet Switch provides 4 PoE ports of 10/100Base-TX plus 3 ports of 10/100Base-TX Ethernet plus 1 port 100FX Multimode SC fiber to enable high speed network at mission-critical environment. This device is designed to be mounted on an industry standard DIN-rail, plus the clearly visible status LEDs provide simple monitoring of port link activity. -
Page 5: Features
When you unpack the product package, you shall find the items listed below. Please inspect the contents, and report any apparent damage or missing items immediately to your authorized reseller. IES-0853 Hardened Web-Smart High Power PoE Ethernet Switch Quick Installation Guide ... -
Page 6: Front Panel Display
Description Steady Power On PW 1,2,3 Power Off 10/100Base-TX or 100Base-FX/BX Steady Network connection is established LNK/ACT Flashing Transmitting or Receiving data Steady Power Device (PD) is connected (High Power) Power Device (PD) is disconnected IES-0853 User Manual Page 6... -
Page 7: Power Input
DC Jack Special Note: The relay output is normal open position when there is no power to the switch. Please do not connect any power source to this terminal to prevent shorting your power supply. IES-0853 User Manual Page 7... -
Page 8: Din Rain Mount
Installation: Place the switch on the DIN rail from above using the slot. Push the front of the switch toward the mounting surface until it audibly snaps into place. Removal: Pull out the lower edge and then remove the switch from the DIN rail. IES-0853 User Manual Page 8... -
Page 9: 10/100Base-Tx Connector
Input Receive Data + Output Transmit Data - Input Receive Data - Input Receive Data + Output Transmit Data + Positive (VCC+) Positive (VCC+) Input Receive Data - Output Transmit Data - Negative (VCC-) Negative (VCC-) IES-0853 User Manual Page 9... -
Page 10: Connecting To Your Network
Step 4: Connect one end of the cable to the switch and the other end to a desired device. Step 5: Once the connections between two end devices are made successfully, turn on the power and the switch is operational. IES-0853 User Manual Page 10... -
Page 11: Web Management
This interface allows you to access the switch using a preferred web browser. This chapter describes how to configure the switch using its web-based browser interface. Default Setting IP address: 192.168.1.10 User Name: admin Password: [Blank] IES-0853 User Manual Page 11... -
Page 12: Logging On To The Switch
192.168.1.10. USER NAME Enter the factory default user name: admin. PASSWORD Enter the factory default password (no password). Or enter a user-defined password if you followed the instructions later and changed the factory default password. IES-0853 User Manual Page 12... -
Page 13: Browser Interface
The web browser interface provides groups of point-and-click buttons at the left field of the screen for configuring and managing the switch. Port Based VLAN Priority Diff Serv Code Point Bit 0 ~ 31, Bit 32 ~ 63 System Setup Firmware Upgrade IES-0853 User Manual Page 13... -
Page 14: Poe
6. Power priority: C Power priority drop-down menu to choose Low , Middle , or High Power priority drop-down list to determine power priority of Port 1 ~ Port 4. 7. OK: OK button to update your settings. IES-0853 User Manual Page 14... -
Page 15: High Power Poe Operation
PD. Fixed power limit(W): C Fixed power limit(W) and type a new fixed power limit 30W for Port 1 ~ Port 4 to provide power to 30W 802.3at PD. OK button to update your settings. IES-0853 User Manual Page 15... -
Page 16: Port Based Vlan
1. VLAN.1 ~ VLAN.7: Click and choose Port 1 ~ Port 8 to be added into VLAN.1 ~ VLAN.7. 2. Cancel: Cancel button to cancel your settings. 3. OK: OK button to update your settings. IES-0853 User Manual Page 16... -
Page 17: Priority
3. 802.1p Level 7 ~ Level 0: Click and set High or Low priority to queue of 802.1p Level 7 ~ Level 0. 4. Cancel: Cancel button to cancel your settings. 5. OK: OK button to update your settings. IES-0853 User Manual Page 17... -
Page 18: Diff Serv Code Point
1. Diff Serv Code Point: Check and set Bit 32 ~ 63 of Diff Serv Code Point to high priority. 2. Cancel: Cancel button to cancel your settings. 3. OK: OK button to update your settings. IES-0853 User Manual Page 18... -
Page 19: System Setup
5. OK: OK button to update your settings. System Reset/Restore to default: 1. Load Default: Load Default button to restore the default settings of the Switch. 2. Reset System: Reset System button to restart the Switch. IES-0853 User Manual Page 19... -
Page 20: Firmware Upgrade
Firmware Upgrade Firmware Update 1. Cancel: C Cancel button to cancel firmware update request. 2. Update: C Update button and wait for firmware update request being processed. IES-0853 User Manual Page 20... -
Page 21: Specifications
EN61000-4-4 (Burst Standards) EN61000-4-5 (Surge Standards) EN61000-4-6 (Induced RFI Standards) EN61000-4-8 (Magnetic Field Standards) IEC60068-2-6 Fc (Vibration Resistance) Environmental Test IEC60068-2-27 Ea (Shock) Compliance IEC60068-2-32 Ed (Free Fall) NEMA TS1/2 Environmental requirements for traffic control equipment IES-0853 User Manual Page 21...
