- Page 1 IES-2880 24 FE + 4 GE Combo SFP Managed Switch -40 to 75C User Manual v1.00 - 1206...
- Page 2 Preface This manual describes how to install and use the Industry Managed Ethernet Switch. This switch introduced here is designed to deliver full scalability with SNMP/RMON web-based management functions by providing: To get the most out of this manual, you should have an understanding of Ethernet networking concepts.
- Page 3 Table of Contents PREFACE ............................... 2 QUICK START GUIDE ............................. 5 ............................5 UNCTIONAL ESCRIPTION ............................6 HYSICAL ESCRIPTION ............................7 ONSOLE ONFIGURATION ............................. 9 ONFIGURATION PRODUCT OVERVIEW ..........................10 ........................10 NDUSTRY ANAGED THERNET WITCH .............................. 10 ACKAGE ONTENTS ............................
- Page 4 ................................ 100 WITCHING ................................. 105 RUNKING STP / R ............................... 106 VLAN ................................119 S ................................. 125 SNMP ................................128 802.1 ................................137 ............................. 142 THER ROTOCOLS SPECIFICATIONS ............................153 APPENDIX A .............................. 154 APPENDIX B .............................. 155 IES-2880 User Manual Page 4...
- Page 5 Quick Start Guide This quick start guide describes how to install and use the Industry Managed Ethernet Switch. This is the switch of choice for harsh environments constrained by space. Functional Description Meets NEMA TS1/TS2 Environmental requirements such as temperature, shock, and vibration for traffic control equipment.
- Page 6 Physical Description The Port Status LEDs and Power Inputs State Indication Steady Power on Power Power off 10/100Base-TX, 100Base-FX/BX A valid network connection Steady established Link/ACT Transmitting or receiving data Flashing ACT stands for ACTIVITY 10/100/1000Base-TX, SFP, 1000Base-SX/LX/BX A valid network connection Steady established Link/ACT...
- Page 7 Terminal Block Power Input +48VDC -48VDC 88-370VDC 90-264VAC 88-370 Earth Ground Protect Ground <Note> Dielectric withstand (Hipot) test for DC power input, must remove metal chip between Earth Ground and Protect Ground of the terminal block power input to avoid damage to the Switch. Console Configuration ...
- Page 8 Logon to Configure Mode (Configure Terminal Mode): will show on the screen. Set new IP address and subnet mask for Switch: on the screen. et new IP address (192.168.1.10) and new IP subnet mask (255.255.255.0) for Switch. IES-2880 User Manual Page 8...
- Page 9 Web Configuration Login the switch: Specify the default IP address (192.168.1.10) of the switch in the web browser. A login window will be shown as below: Enter the factory default login ID: root. Enter the factory default password (no password). IES-2880 User Manual Page 9...
- Page 10 Product Overview Industry Managed Ethernet Switch Front View Package Contents When you unpack the product package, you shall find the items listed below. Please inspect the contents, and report any apparent damage or missing items immediately to your authorized reseller. ...
