Page 1: User Manual
IES-0510 4 FE + 1 MM SC Unmanaged Switch -10 to 60, DIN-rail User Manual v1.00 - 1206... -
Page 2: Preface
To get the most out of this manual, you should have an understanding of Ethernet networking concepts. In this manual, you will find: Features on the switch Illustrative LED functions Installation instructions Specifications IES-0510 User Manual Page 2... -
Page 3: Table Of Contents
INSTALLATION ..............................7 ..........................7 ELECTING A ITE FOR THE WITCH DIN R .............................. 7 OUNTING ............................8 ONNECTING TO OWER ..........................9 ONNECTING TO ETWORK SPECIFICATIONS ............................. 11 APPENDIX A – CONNECTOR PINOUTS ......................12 IES-0510 User Manual Page 3... -
Page 4: Product Overview
IES-0510 4 FE + 1 MM SC Unmanaged Switch -10 to 60, DIN-rail Quick Installation Guide CD User Manual IES-0510 User Manual Page 4... -
Page 5: Product Highlights
Operating voltage and Max. current consumption: 0.2A @ 12VDC, 0.1A @ 24VDC, 0.05A @ 48VDC. Power consumption: 2.4W Max. Power Supply: DC Terminal Block power input, 12-48VDC with polarity protection. Plastic compact DIN-Rail Industrial case design. DIN-Rail mounting ability. IES-0510 User Manual Page 5... -
Page 6: Front Panel Display
LED is dark. Physical Ports This switch provides: Five 10/100Base-TX ports Four 10/100Base-TX ports + one 100Base-FX port One 10/100Base-TX port + one 100Base-FX port Connectivity RJ-45 connectors SC or ST connector on 100Base-FX fiber port IES-0510 User Manual Page 6... -
Page 7: Installation
Installation: Place the switch on the DIN rail from above using the slot. Push the front of the switch toward the mounting surface until it audibly snaps into place. Removal: Pull out the lower edge and then remove the switch from the DIN rail. IES-0510 User Manual Page 7... -
Page 8: Connecting To Power
Step 1: Connect the DC power cord to the plug-able terminal block on the switch, and then plug it into a standard DC outlet. Step 2: Disconnect the power cord if you want to shut down the switch. The Terminal Block Power Input Power Ground Earth Ground IES-0510 User Manual Page 8... -
Page 9: Connecting To Your Network
3, 4, 5 100Base-TX RJ-45 100/200 Mbps 2-pair UTP/STP Cat. 5 100 m MMF (50 or 62.5μm) 100Base-FX SC, ST 100/200 Mbps 2 km SMF (9 or 10μm) 100Base-FX SC, ST 100/200 Mbps 15, 40, or 75 IES-0510 User Manual Page 9... - Page 10 Step 4: Connect one end of the cable to the switch and the other end to a desired device. Step 5: Once the connections between two end devices are made successfully, turn on the power and the switch is operational. IES-0510 User Manual Page 10...
-
Page 11: Specifications
EN61000-4-3 (Radiated RFI Standards) EN61000-4-4 (Burst Standards) EN61000-4-5 (Surge Standards) EN61000-4-6 (Induced RFI Standards) EN61000-4-8 (Magnetic Field Standards) EN61000-4-11 (Voltage Dips Standards) Environmental Test IEC60068-2-6 Fc (Vibration Resistance) Compliance IEC60068-2-27 Ea (Shock) IEC60068-2-32 Ed (Free Fall) IES-0510 User Manual Page 11... -
Page 12: Appendix A - Connector Pinouts
Regular Ports Uplink port Output Transmit Data + Input Receive Data + Output Transmit Data - Input Receive Data - Input Receive Data + Output Transmit Data + Input Receive Data - Output Transmit Data - IES-0510 User Manual Page 12...
