X-Vision Digital Video Recorder User Manual page 61

7.6 Viewing Remote Recordings
In order to view remote recordings, just click SEARCH BUTTON. Then the below dialog box will come out.
Select date & time. Then click OK to continue remote playback.
1. Date Selection Menu
The date having recording is displayed
colored. Click the date that you want to
search from.
3. Video Information
Check on each to displayed resoultion,
codec type or recording type on
recording images.
Upon clicking OK button, playback screen
will pop up. The usage is the same when
server playback.
2. Search Time
The time having recording is displayed colored (FPS:Green,
Motion:Blue, Alarm-In:Orange). Move the red bar to the time
that you want to play.
5. OK
6. Cancel
Click to play
selected images.
X-Vision
4. Record Source
Select one of Network Record Data
Or Client Record Data
61
