5.3.2 Setting Motion & Color Properties
In order to set motion & color properties, click MOTION & COLOR SETUP button and select each camera
icon on the above.
Color setting
preview
window
Motion
sensitivity
1. Setting Color
Move the below slide bars in order to get color setting that you desire to have.
- General is for recording image adjustment.
- Overay is for display image adjustment.
2. Setting Motion Properties
- Motion sensitivity : move the slide bar ranging from Low to High
- Motion area setting :
Press "Display Motion Area Button" to view motion area. Then motion setting area will be displayed in blue color. To deleted
the area, draw with right-mouse click. To draw area again, draw with left-mouse click. You can use "Brush Size Adjust
Button" together.
To set whole areas for motion, press "Draw On All Area Button". To delete whole motion area, press "Delete On All Area
Button".
Display Motion Area
Draw On All Area
Delete On All Area
X-Vision
Back to default
color
Brightness control
Contrast control
Hue control
ChrU control
ChrV control
Brush Size Adjust
35
