X-Vision Digital Video Recorder User Manual page 38

Click Action button to select alert mode when motion event occurs.
- Display Motion Areas : makes motion area blue shaded
- Sound Alert : makes beep sound through PC speaker
- E-mail : sends e-mail with captured image to registered address (Refer to E-mail Setup)
Alert delay time setting is 5 to 30 sec
- Pop-up : displays one full screen of the camera view with motion event
Pop-up time can be set for 5 to 30 sec
- Phone Alert : calls to registered no. upon motion event (Refer to Dial-up Setup)
- Alarm-Out : sends digital outputs (alarm, lamp and so on) checked upon motion event
4. If you don't check on Motion Recording, set frame per second on FPS Recording slide bar. Another slide bars is inactive.
If you check on Motion Recording or DI nos, set frame per second for event recording on FPS Recording slide bar and set
non event frames on Non-event FPS slide bar.
For recording upon event
For recording without event
