TRC UNIVERSAL IRRIGATION REMOTE CONTROL Operation And Installation Manual page 28

32 Station Connector Wiring Color Codes
Valve
1 Black
2 White
3 Red
4 Green
5 Orange
6 Blue
7 White w/ black stripe
8 Red w/ black stripe
9 Green w/ black stripe
10 orange w/ black stripe
11 Blue w/ black stripe
12 Black w/ white stripe
13 Blue w/ red stripe
14 Red w/ green stripe
15 Orange w/ green
16 Black w/ white and red stripe
17 White w/ black and red stripe
18 Red w/ black and white stripe
Wire Color
1(800) 275-8558
18342 Redmond Way Bldg B, Redmond, WA 98052
Phone: (425) 885-6362 Fax: (425) 883-4667
Valve
19 Green w/ black and white stripe
20 Orange w/ black and white stripe
21 Blue w/ black and white stripe
22 Black w/ red and green stripe
23 White w/ red and green stripe
24 Red w/ black and green stripe
25 Green w/ black and orange stripe
26 Orange w/ black and green stripe
27 Blue w/ white and orange stripe
28 Black w/ white and orange stripe
29 White w/ red and orange stripe
30 Orange w/ white and blue stripe
31 White w/ red and blue stripe
32 Black w/ white and green stripe
Com Orange w/ red stripe
M.V. Green w/ white stripe
24 V Blue w/ white stripe
Wire Color
