Instructions also provided with PCC.
Do not have the Receiver plugged into connector cable
while installing connector or damage may occur.
Do not have 24VAC transformer plugged into Receiver
with the connector when the connector has 24VAC
Step 1:
Step 1:
Use (figure 4 from the pamphlet with your PCC) as a
Use (figure 4 from the pamphlet with your PCC) as a
pattern to locate the mounting holes to be drilled
pattern to locate the mounting holes to be drilled
through the controller.
through the controller.
Step 2:
Step 2:
Peel off sticker and attach gasket on back of housing.
Peel off sticker and attach gasket on back of housing.
Step 3:
Step 3:
Peel off sticker and attach gasket to inside door. Make
Peel off sticker and attach gasket to inside door. Make
sure gasket is snug against side walls for maximum
sure gasket is snug against side walls for maximum
seal.
seal.
Step 4:
Step 4:
Locate 1" socket head cap screw and insert thoughhole
Locate 1" socket head cap screw and insert thoughhole
on door. Slip on retainer ring approximately 3/16" from
on door. Slip on retainer ring approximately 3/16" from
threaded end of cap screw.
threaded end of cap screw.
Step 5:
Step 5:
Mount housing to controller using two 6-32 x 3/4"
Mount housing to controller using two 6-32 x 3/4"
machine screws, two flat washers, two lock washers,
machine screws, two flat washers, two lock washers,
and two hex nuts.
and two hex nuts.
Step 6:
Step 6:
Attach D-Sub connector to the inside housing with two
Attach D-Sub connector to the inside housing with two
4-40 x 9/16" machine screws. Do so by first inserting
4-40 x 9/16" machine screws. Do so by first inserting
the end of wires through the 1/2" hole in the sprinkler
the end of wires through the 1/2" hole in the sprinkler
controller. Attach connector with the longer row of pins
controller. Attach connector with the longer row of pins
to the left. Hold connector to highest position while
to the left. Hold connector to highest position while
tightening. Follow wiring code for connecting cables.
tightening. Follow wiring code for connecting cables.
Wiring Your PCC
from the controller!
800-275-8558 www.remotecontroltech.com
Warning
23
