Effect: One of a number of audio processes that can be
applied to a signal to modify it, such as reverb, flanging,
phasing, delay etc.
Effects rack: A virtual rack of internal processors. See
Virtual rack.
Envelope: 1. How a sound or audio signal varies in
intensity over time. 2. The visual representation of such,
usually shown on a graph in a GUI channel strip.
EQ: Abbreviation for 'equaliser' or 'equalisation' .
Equalisation: Adjusting the frequency response so that
the levels of all frequencies are equal or the same. Bass and
treble controls are equalisation controls.
EtherCon®: A cable connector for data transfer
interconnections, which is more robust than the basic RJ45.
F
Fader: Slider-type device for precise adjustment of signal
level or volume of a channel.
Fast strip: One of the strips in the input, mix and output
fast zones. See Input fast strip, Mix fast strip, Output fast
strip and Fast zone.
Fast zone: An area on a bay that contains quick controls.
See Input fast zone, Mix fast zone, Output fast zone and
Fast strip.
FB: Abbreviation for 'front-back' . A term used in surround
panning.
Feedback: See Acoustic feedback.
Filter: A device for removing frequencies above or below
certain levels.
FOH: Abbreviation for 'front of house' . The area in a theatre
used by the public. Used to describe a control centre being
used to control the sound that the audience will hear (and
not the performers' monitor system).
Frequency: The number of times that a sound wave's cycle
repeats within one second.
Fricative: A consonant, such as 'f' or 's' , produced by the
forcing of breath through a constricted passage.
From section: The leftmost area of the patching screen
that contains the source patch connectors. See Patching.
124
G
Gain: Another term for signal level.
Gain reduction (compressor): Decrease in gain when
input signal is above threshold. See Gain.
GEQ: Abbreviation for 'graphic equaliser' . See Graphic EQ.
GEQ rack: A virtual rack of GEQs. See Virtual rack.
Granularity: A measure of the size of components or a
description of the components comprising a system.
Graphic EQ: A form of EQ that has a number of faders for
controlling the gain of the audio signal. The faders are set
at frequency bands that are evenly-spaced according to
octaves.
GUI: Abbreviation for 'graphical user interface' .
GUI channel strip: Right section of a GUI screen that
represents the processing area of the input or output
channel strip selected to the control surface.
GUI menu: A menu selectable at either GUI screen by
clicking the home button (upper-left corner).
GUI screen: One of the M32's two screens, which comprise
the GUI.
H
HPF: Abbreviation for 'high pass filter' . A filter that removes
lower frequencies from a signal, leaving the higher
frequencies unaffected.
Hum: Undesirable low frequency tone present in a signal
due to grounding problems or proximity to a power source.
Hz: Symbol for 'Hertz' . A unit of frequency equal to one
cycle of a sound wave per second.
I
I zone: Area on the master bay that contains the operator-
assignable effects controls.
I/O: Abbreviation for 'input/output' .
ID: Abbreviation for 'identification' .
Ident: Scale marking, or gradation, around a control knob
to help indicate the current setting and to assist in accurate
adjustment.
Impedance (Z): Opposition to the flow of alternating
www.theaudiospecialists.eu
M32 - Digital Console
current in a circuit, measured in ohms.
K
Kernel: For computers, the kernel is the central component
of most operating systems.
L
LCD select button: LCD button in the input fast strips
and VCA groups, used for channel/group navigation and
selection, and operator feedback.
LFE: Abbreviation for 'low frequency effects' . Typically, the
' . 1' in '5.1 surround' is an LFE channel.
LFO: 1. Abbreviation for Low-Frequency Oscillation, an
electronic signal which is usually below 20 Hz and creates
a rhythmic pulse or sweep. This pulse or sweep is often
used to modulate synthesizers, delay lines and other audio
equipment in order to create effects used in the production
of electronic music. 2. Abbreviation for Low-Frequency
Oscillator, the device itself which produces low-frequency
oscillation.
Linux: Also known as 'Linux kernel' . Operating system
kernel used by a family of Unix-like operating systems. See
kernel.
LS: Abbreviation for 'left surround' . The left rear speaker in a
5.1 surround system.
M
MADI: Abbreviation for 'multi-channel audio digital
interface' .
Master bay: Control area for masters, automation, comms,
monitoring etc. Also contains the primary navigation zone.
Masters: The three master channels (mono and stereo left
and right) in the master bay.
MB: Abbreviation for 'megabyte' .
MC: Abbreviation for 'master controller' .
Meter: Visual device to indicate the level of a signal.
Meters screen: One of the GUI screens. This is the default
screen of the master bay.
Mic: Abbreviation for 'microphone' .
Microphone: Device for converting sound waves into
audio signals.
User Manual
MIDI: Acronym for 'musical instrument digital interface' . A
digital signal system standard that facilitates integration of
musical instruments, such as synthesizers and guitars, with
computers.
Mix: 1. A signal that contains a combination of signals,
such as a pair of stereo signals with numerous effects. 2.
The act of creating such a combination. 3. A type of bus. See
Bus.
Mix bay: Control area for outputs and groups.
Mixer: 1. A console or other device that blends input
signals into composite signals for output. 2. An engineer/
technician who carries this out, especially during a live
performance.
mm: Symbol for 'millimetre' (one thousandth of a metre).
MON: Abbreviation for 'monitor' , used to describe a control
centre being used to mix the signals sent to the stage
monitor speakers.
Monitor: 1. Speaker(s) used for listening to a mix or live
audio. 2. The act of listening to a mix or live audio.
Monitor A: Primary monitor bus system.
Monitor B: Secondary monitor bus system.
Monitors: Control area on the master bay for monitoring
the A and B signal paths.
Mono: A single signal.
Mute: Function that allows a channel's signal to be
silenced.
Mute safe: Function that means a mute cannot be
controlled by scene recall or auto-mutes.
N
N/A: Abbreviation for 'not applicable' .
nm: Symbol for nanometre (one billionth of a metre).
Normalise: To boost the amplitude of a digital sound so
that it is as high as it can be without clipping (0 dB).
Normalisation: An automatic process whereby the gain of
all program material is adjusted so that the peak level will
just arrive at 0 dB.
Normalised connection: Also known as 'normalled
connection' . A connection that allows a signal to pass
through it when no plug is inserted in it, but breaks the
