RECORDER
USB Port
Connect a USB stick to install firmware updates and
to record performances.
ACCESS
The ACCESS LED illuminates to indicate that a USB
stick is in place and is being written to or read from.
VIEW
Press the VIEW button to open the USB Recorder
pages on the Main Display.
Operation
The M32 offers functionality for playing back un-
compressed stereo WAV files, and for recording any
available signal in the console directly onto USB
stick or compatible USB hard drive.
To record to a USB stick, perform the following
steps:
1. Plug a FAT-formatted (FAT12, FAT16,
FAT32) USB stick into the USB port as
illustrated above.
2. Press the VIEW button in the RECORDER
panel. This will then display a graphic
representation of an analogue tape deck
on the Main Display home tab.
3. On the config tab you can select the
source of the recording , the default being
the main L & R outputs.
4. Press the fifth rotary control, labelled
Record.
5. To adjust the volume during playback,
press the AUX IN/USB button next to
the input channel faders, and adjust the
volume using AUX faders 7 & 8.
30
1.
USB Port
2.
Access LED
3.
View Button
www.theaudiospecialists.eu
M32 - Digital Console
User Manual
31
