OPERATORS MANUAL
Telex Communications (UK) Ltd,
Klark Teknik Building,
Walter Nash Road,
Kidderminster.
Worcestershire.
DY11 7HJ.
England.
Tel:+44 1562 741515
Fax:+44 1562 745371
Website: www.midasconsoles.com
MIDAS Siena audio mixing console
DOC02-Siena Issue 1.0 - Janruary 2005
©
Telex Communciations (UK) Ltd.
In line with the company's policy of continual improvement, specifications and function may be
subject to change without notice. This Operators Manual was correct at the time of writing. E&OE.

Advertisement

Table of Contents
loading

Related Manuals for Midas SIENA

Summary of Contents for Midas SIENA

  • Page 1 Tel:+44 1562 741515 Fax:+44 1562 745371 Website: www.midasconsoles.com MIDAS Siena audio mixing console DOC02-Siena Issue 1.0 - Janruary 2005 © Telex Communciations (UK) Ltd. In line with the company’s policy of continual improvement, specifications and function may be subject to change without notice. This Operators Manual was correct at the time of writing. E&OE.
  • Page 3 Important Safety Instructions Important Safety Instructions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE AVIS: RISQUE DE CHOC ELECTRIQUE. NE PAS OUVRIR These symbols are internationally accepted symbols that warn of potential hazards with electrical products.

  • Page 5: Declaration Of Conformity

    We, Telex Communications (UK) Ltd Klark Teknik Building, Walter Nash Road, Kidderminster, Worcestershire, DY11 7HJ. Declare that a sample of the following product:- Product Type Number Product Description Nominal Voltage (s) Current Freq Siena Professional Audio 115V AC 2.2A 50/60Hz Mixing Desk 230V AC 1.1A...

  • Page 7: Table Of Contents

    Welcome Thank You for using a Midas Siena mixing console. The Siena has been developed to meet the needs of even the most demanding live sound applications. The console delivers both the quality of build and superior audio performance that you would expect from a Midas.

  • Page 8: Connections

    ATTENTION The following special limitations must be observed in order to maintain safety and electromagnetic compatibility performance. Power Connection Electric Fields The console should only be operated with the power If the console is operated in an electromagnetic field that is supply connected to ground via the ground in the mains amplitude modulated by an audio frequency signal, the signal to connector.
  • Page 9 Input Channel Operators Manual - Page 7...

  • Page 10: Input Channels

    Input Channels Input Channels Rear Panel The Siena channel inputs are located on the rear of the console. Each channel provides: one insert point on a single TRS jack socket. insert one direct output on a single impedance balanced quarter-inch jack socket...

  • Page 11: Channel Equalisation

    Input Channels Input Channels power Channel Equalisation mic gain Each input channel of the Siena has a four (4) band sweep EQ allowing tonal control over the input signal. hi-pass treble Treble (Gain) - The gain of the treble equaliser is continuously variable from -15dB to +15dB with a centre detent at 0dB.

  • Page 12: Mix Sends (Auxiliary Sends And Groups)

    In addition, you may require both mono and stereo mixes to feed a mixture of floor monitors and wireless in-ear monitoring. By configuring any odd/even pair of the Siena's mix busses for stereo operation, you have complete flexibility over the console layout.

  • Page 13: Routing To Stereo Master Outputs

    Input Channels Input Channels power Routing to the Stereo Master Output In addition to the 16 mix bus sends, Siena features a stereo master mic gain output. Typically, this would be used to generate the Front of House (FOH) mix hi-pass for hybrid FOH/monitor applications.

  • Page 14: Metering And Automutes

    (AFL) or pre fader (PFL) on either 11-12 Auto Mute 1, 2, 3, 4 & 5 The Siena has main monitor headphone five auto mute groups that can be outputs.

  • Page 15: Master Section : Mix Bus Outputs

    Master Section Operators Manual - Page 13...

  • Page 16: Mix Bus Outputs (Auxiliary Send/Group Masters)

    Mix Bus Outputs (Auxiliary Send/Group Masters) The Siena has 16 mix bus outputs for use as auxiliary sends or group outputs. The console uses a generic approach to the mix bus structure to enable it to cover a wide range of applications.

  • Page 17: Rear Panel And Metering

    Mix Bus Outputs (Auxiliary Send/Group Masters) direct direct Metering On Siena, every one of the 16 mix bus outputs features its stereo own dedicated LED meter, providing a constant overview of insert insert every mix leaving the console. MUTE...

  • Page 18: Direct Input To Mix

    Mix Bus Outputs Direct Input to Mix 1 mix meters 2 In addition to the console's input channels, Siena features a single stereo direct input (line level) which may be added to any of the 16 mix bus outputs or stereo master.

  • Page 19: Mix Bus 1-8 Master Controls

    16 mix bus output auto auto mute mute in stereo mode.) Please see Page mutes to auto mute group 5. The Siena 10 for more details on input has five auto mute groups that can be auto auto channel controls.

  • Page 20: Mix Bus 9-16 Master Controls

    Master Section: Master Section: Mix Bus Outputs Mix Bus Outputs Auxiliary Send/Group Masters 1 mix meters 2 Mix Bus 9-16 Master Controls The master controls for mix bus outputs 9-16 are identical to those for mix bus outputs 1-8 with the addition of the following features: 9 mix meters 10 Pan The signal from the mix bus output...

  • Page 21: Rear Panel And Metering

    Master Section: Master Section: Stereo Master & Monitoring Controls Stereo Master & Monitoring Controls Rear Panel The Siena's stereo master and monitoring outputs are located on the insert insert direct in rear of the console and provide: master meters left...

  • Page 22: Direct Input Master Controls

    SOLO SOLO input output MUTE The Siena provides an internal tone generator which may be routed to any of the console's 16 mix bus and stereo local auto mute master outputs. mono sum When enabled, the output of the tone generator is added to the talk bus where it may be combined with the...

  • Page 23: Talkback

    Talkback The Siena provides talkback which may be routed to any of the console's 16 mix bus and stereo master outputs. There are two options for connecting talkback sources to the console: On the front panel, a conveniently located internal talk mic socket, supplied with 48V phantom power, allows connection of a condenser microphone.

  • Page 24: Auto Mute Masters

    Stereo Master & Monitoring Controls master meters left right Auto Mute Masters The Siena provides five auto mute groups commonly used to provide easy muting of similar channels. For example: Channels Reason Drum Mics Allows the engineer to mute the whole drum kit at once.

  • Page 25: Local Monitoring And Headphone Outputs

    This is because the PFL Out is typically used to connect the PFL bus to a direct to masters second console. For example, if the Siena is working with the support band, it may be necessary to feed its PFL generator output to the main band's console.

  • Page 26: The Solo System (Afl And Pfl)

    Solo Hierarchy input / output 5-16 In addition to the master AFL/PFL selector, Siena's hierarchical solo system allows you to quickly switch between masters monitor monitoring say an input channel in PFL and a mix bus output in AFL. The local monitor and headphone outputs are...

  • Page 27: Helix Digital Equaliser And Solo Tracking System

    HELIX Digital Equaliser Solo Tracking System The Siena console features a Solo Tracking System which allows any of the 16 mix bus master or stereo master solos on the console to trigger auto solo messages on the Klark Teknik DN9340 (HELIX) digital graphic equaliser.

  • Page 28: Stereo Master Output Controls

    Stereo Master Output Controls In addition to the console's 16 mix bus outputs, the Siena provides a stereo master typically used to generate the front of house (FOH) mix, if required. Independent controls are provided for the left and right sides of the stereo master retaining ultimate control at all times.

  • Page 29: Setting Up The Siena

    Setting up the Siena Operators Manual - Page 27...

  • Page 30: The Effect Of Eq

    Setting the Correct Input Gain The Siena’s input channel has a mono microphone and line input. Gain is provided on these channels to allow the operator to obtain the optimal signal for the system.
  • Page 31 Unity gain is a gain of 1 (i.e. no gain or attenuation is applied to a signal). If a signal entered a mono line level input of the Siena at 0dBu and the gain was set to +15dB (an internal 15dB attenuation sets the net gain to 0dB), then the signal was routed to each output at 0dB, the channel fader was set to 0dB and each output fader was set to 0dB, the output should be 0dBu (or unity).

  • Page 32: Signal Processing And Amplifiers

    Graphical equalisers have the same problems as the Siena’s EQ. If excessive boost is applied to the signal, the graphic equaliser’s output may be overloaded. If, the output of the Siena is higher than the maximum input level of the graphic, the input of the graphic may be overloaded.
  • Page 33 Busses and Routing Siena has a master stereo bus plus 16 mix bus outputs which may be used as auxiliary sends or group outputs depending on the application of the console. This generic approach to the mix bus structure enables the console cover a wide range of applications.
  • Page 34 Dual Purpose Front of House (FOH) and Monitor Applications With its flexible routing and feature set, the Siena is happy to run both the front of house (FOH) mix and provide monitor mixes for the artists on stage. In this dual purpose application, you will want to use some of the 16 mix busses, as above, to generate your monitor feeds to the stage, while the remaining busses can be used to generate audio sub groups.
  • Page 35 Setting Up The Siena Setting Up The Siena Busses and Routing Auxiliary Sends Typical Configuration When determining how many mix busses you wish to use for auxiliary sends, you may wish to consider the following. We've also provided some recommendations on how to configure each send, depending on its application.

  • Page 37: Functional Block Diagrams

    Functional Block Diagrams Operators Manual - Page 35...

  • Page 38: Mono Input Diagram

    Operators Manual - Page 36...

  • Page 39: Mix Output Diagram

    Operators Manual - Page 37...

  • Page 40: Master Module Diagram

    Operators Manual - Page 38...

  • Page 41: Dimensions And Weights

    Dimensions and Weights Operators Manual - Page 39...
  • Page 42 Dimensions and Weights Operators Manual - Page 40...

  • Page 43: Rear Panel Description

    Rear panel Description Operators Manual - Page 41...

  • Page 44: Rear Panel Description

    Rear Panel Description Operators Manual - Page 42...

  • Page 45: Specification And Features

    Specification and Features Operators Manual - Page 43...
  • Page 46 Siena Features Siena Features The following list of features is based upon the 48-channel frame size console. The 48-channel Siena features: 48 mono input channels 16 Mix Bus Outputs Mono Channels: 4 Swept Frequency Bands (Treble, Hi Mid, Lo Mid, Bass)
  • Page 47 Siena Specification Siena Specification Internal Power Supply Type Switching Line Voltage 90 - 240V AC Line Frequency 50/60Hz Input Impedance Microphone 1k5 ohm Balanced Line 10k ohm Balanced Input Gain (all faders at 0dB) Microphone Continuously variable from +15dB to +60dB...
  • Page 48 Redundancy 32 - 56 The internal supplies on the 64 channel Siena should be switched on at approximately the same time so that excessive load is not applied to any single supply. The external power supply can be used to add or increase redundancy or to replace the internal supplies. The external supply has a “daisy chain”...

  • Page 49: Crib Sheet

    power power power power power power power power mic gain mic gain mic gain mic gain mic gain mic gain mic gain mic gain hi-pass hi-pass hi-pass hi-pass hi-pass hi-pass hi-pass hi-pass Crib Sheet Input Crib Sheet Input treble treble treble treble treble...
