Transport WR Series Installation Guide
Reset button
This is located on the underside of the unit near the front (just behind the DTE LED), and
can be accessed through a 2.5mm hole using pencil tip or similar implement. Holding the
reset button down gently for 5 seconds when the unit is powered up and operational (i.e.
has finished booting), will cause the factory settings to be loaded into flash and then re-
boot. During this time you will see a pattern of alternating LEDs flashing followed by the
normal boot sequence. Do not remove power from the unit during this operation, as
corruption of the flash memory may occur.
1.3
Optional features.
Routers are available with a variety of hardware options, including:
1 x ASY
3 x ASY
1 x SYN
1 x GPS
1 x ISDN BRI
Only one of the above options can be fitted and will occupy the area of the rear panel
normally covered with the blanking plate. For example, if the GPS option is fitted, the rear
panel will appear as shown above.
Provides an additional asynchronous serial port using a 25-way D
connector
Provides three additional asynchronous serial ports using RJ45
connectors.
Provides an X.21/RS422/RS232 synchronous serial port using a
25-way D connector.
Provides GPS geo-location capability.
Provides an ISDN Basic Rate Interface (BRI) via an RJ45 socket.
This can be configured either as a TE (terminal endpoint) or as
NT-1 (network termination). The option also includes an additional
asynchronous serial port via a second RJ45 socket.
8
