Transport WR Series Installation Guide
3 General Specifications
Model numbers
Power supply
Dimensions / Weight
Operating temp. range
WR41-E
GSM/GPRS/EDGE
modem
WR41-H
GSM/GPRS/EDGE/
UMTS/HSDPA modem
WR41-U
GSM/GPRS/EDGE/
UMTS/HSDPA/HSUPA
modem
Transport WR41-E, H, U, C
5V DC / 3A
W6.77 x D14.33 x H1.26 inches, 1.17 lbs
-4 to +122 degrees Fahrenheit, -20 to +50 degree Celsius
Quad-band GSM 850/900/1800/1900 MHz EDGE (E-
GPRS) multi-slot class 10 (max 236.8 kbps downlink),
mobile station class B, modulation and coding scheme
MCS1-9
GPRS multi-slot class 10, mobile station class B, PBCCH
support, coding schemes CS 1-4
HSDPA 1.8 Categories 1-4, 11 and 12
HSDPA 3.6 Categories 5 and 6
UMTS: 384 Kbps downlink, 384 Kbps uplink
MO 0201: 850/1900/2100 (Rx diversity) MHz
Quad-band GSM 850/900/1800/1900 MHz EDGE (E-
GPRS) multi-slot class 12 (max 236.8 kbps downlink),
mobile station class B, modulation and coding scheme
MCS1-9
GPRS multi-slot class 12, mobile station class B, PBCCH
support, coding schemes CS 1-4
HSUPA mode: 2 Mbps Category 5
HSDPA 1.8: Categories 1-4, 11 and 12
HSDPA 3.6: Categories 5 and 6
HSDPA 7.2: Categories 7 and 8
UMTS: 384 Kbps downlink, 384 Kbps uplink
MO 0301: 850/1900/2100 (Rx diversity) MHz
MO 0302: 850 (Rx Diversity) / 1900 (Rx Diversity) / 2100 MHz
Equalization and Rx Diversity at the same time Quad-band
GSM 850/900/1800/1900 MHz EDGE (E-GPRS) multi-slot
class 12 (max 236.8 kbps downlink), mobile station class B,
modulation and coding scheme MCS1-9
GPRS multi-slot class 12, mobile station class B, PBCCH
support, coding schemes CS 1-4
15
